AMD Radeon HD 7480D

AMD Radeon HD 7480D

L'AMD Radeon HD 7480D o HD7480D è una scheda grafica per processori desktop delle APUs Trinity APUs di AMD. E' una versione ridotta con appena 128 dei 384 shaders ed è integrata nelle APUs della serie A4. Si basa sull'architettura VLIW4 della serie di schede grafiche desktop Radeon HD 6900 e non ha memoria grafica dedicata.

La Trinity deve il suo nome al fatto che consiste in tre diverse architetture. I cores CPU si basano sull'architettura Piledriver (successore della Bulldozer), i cores GPU sulla Northern Islands (serie desktop HD 6900) ed il motore video e la connettività multi-display derivano dalla nuova architettura GPU Southern Islands (serie HD 7900).

Il decoder video UV3 integrato (Avivo HD) consente la piena decodifica Multi-View Codec (MVC), MPEG-4 Part 2 (DivX, xVid), MPEG-4 AVC/H.264 ed Adobe Flash HD.

Le prestazioni con i giochi complessivamente sono paragonabili ad una GPU Intel HD Graphics 4000. Tuttavia, a causa della lenta componente CPU, molti giochi potrebbero portare la CPU al limite e di conseguenza i frame rates sono più bassi (i.e. con settaggio di risoluzione e dettagli bassi).

Radeon HD 7000D Serie

Radeon HD 7660D 384 @ 0.63 - 0.8 GHz
Radeon HD 7560D 256 @ 0.76 GHz
Radeon HD 7480D 128 @ 0.61 - 0.72 GHz
Nome in codiceTrinity
ArchitetturaTerascale 3
Pipelines128 - unified
Velocità del core614 - 724 (Boost) MHz
Memoria condivisasi
APIDirectX 11, Shader 5.0, OpenGL 4.2
tecnologia32 nm
Data dell'annuncio26.09.2012
CPU in Radeon HD 7480DGPU Base SpeedGPU Boost / Turbo
AMD A4-53002 x 3400 MHz, 65 W724 MHz? MHz

Benchmark

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.2 pt (1%)
AMD Radeon HD 8180
0.06605 -67%
...
0.1699 -16%
0.1767 -13%
0.1827 -10%
0.1859 -8%
0.1911 -6%
0.1966 -3%
0.1972 -3%
0.1975 -3%
0.2 -1%
AMD Radeon HD 7480D
0.2027
0.2068 2%
Intel HD Graphics (Broadwell)
0.2109 4%
AMD Radeon HD 6450 GDDR5
0.2114 4%
0.2116 4%
0.2164 7%
0.2187 8%
0.2264 12%
AMD Radeon R2 (Stoney Ridge)
0.233 15%
0.2332 15%
...
33.3 16328%
0%
100%
3DMark - 3DMark Cloud Gate Graphics
4236 Points (1%)
3DMark - 3DMark Fire Strike Standard Score
412 Points (1%)
3DMark - 3DMark Fire Strike Standard Graphics
445 Points (1%)
3DMark - 3DMark Ice Storm Graphics
41542 Points (5%)
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
2595 Points (1%)
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
2269 Points (1%)
62 -97%
...
2201 -3%
2203 -3%
2207 -3%
2212 -3%
ATI Mobility Radeon HD 560v
2216 -2%
2220 -2%
2222 -2%
AMD Radeon R4 (Stoney Ridge)
2243 -1%
2259 0%
AMD Radeon HD 7480D
2269
2322 2%
ATI Mobility Radeon HD 5165
2362 4%
2392 5%
2441 8%
2453 8%
2478 9%
2527 11%
2552 12%
AMD Radeon HD 6755G2
2593 14%
...
170928 7433%
0%
100%
3DMark 03 - 3DMark 03 - Standard
16956 Points (9%)
3DMark 05 - 3DMark 05 - Standard
10626 Points (12%)
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
5450 Points (7%)
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
6391 punti (5%)
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
21.4 fps (7%)
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
19.1 fps (1%)
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
39 Samples/s (0%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
84 Samples/s (0%)
ComputeMark v2.1 - ComputeMark v2.1 Result
382 punti (0%)
- Valori di benchmark per questa scheda grafica
- Valori medi di benchmark per questa scheda grafica
* Numeri più piccoli rappresentano prestazioni supeiori

Benchmarks per i giochi

I seguenti benchmarks deirivano dai benchmarks dei portatili recensiti. Le prestazioni dipendono dalla scheda grafica utilizzata, dal clock rate, dal processore, dai settaggi di sistema, dai drivers, e dai sistemi operativi. Quindi i risultati non sono rappresentativi per i portatili con questa GPU. Per informazioni dettagliate sui risultati del benchmark, cliccate sul numero di fps.

basso 1024x768
9.5  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
72  fps    + Confronta
medio 1366x768
21.3  fps    + Confronta
alto 1920x1080
12.5  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
Evolve

Evolve

2015
basso 1024x768
10.7  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
19.4  fps    + Confronta
medio 1366x768
15.5  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
43.7  fps    + Confronta
medio 1366x768
17.6  fps    + Confronta
alto 1366x768
7.6  fps    + Confronta
ultra 1920x1080
5.1  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
basso 1024x768
30.9  fps    + Confronta
medio 1366x768
19.6  fps    + Confronta
alto 1366x768
7.6  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
26.5  fps    + Confronta
medio 1366x768
18.4  fps    + Confronta
alto 1366x768
12.7  fps    + Confronta
ultra 1920x1080
3.9  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
40  fps    + Confronta
medio 1366x768
24  fps    + Confronta
alto 1366x768
12  fps    + Confronta
ultra 1920x1080
5  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
F1 2013

F1 2013

2013
basso 1024x768
42  fps    + Confronta
medio 1366x768
30  fps    + Confronta
alto 1366x768
26  fps    + Confronta
ultra 1920x1080
12  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
Fifa 14

Fifa 14

2013
alto 1366x768
70  fps    + Confronta
ultra 1920x1080
45.5  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli ultra.
basso 1024x768
27.9  fps    + Confronta
medio 1366x768
22  fps    + Confronta
alto 1366x768
16.7  fps    + Confronta
ultra 1920x1080
2.8  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1280x720
19.3  fps    + Confronta
medio 1366x768
17.2  fps    + Confronta
alto 1366x768
10  fps    + Confronta
ultra 1920x1080
4.9  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
29.4  fps    + Confronta
medio 1366x768
15.1  fps    + Confronta
alto 1366x768
7.1  fps    + Confronta
ultra 1920x1080
4.2  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
24.9  fps    + Confronta
medio 1366x768
23  fps    + Confronta
alto 1366x768
4.7  fps    + Confronta
ultra 1920x1080
0 (!)  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
Dota 2

Dota 2

2013
basso 1024x768
52.5  fps    + Confronta
medio 1366x768
28  fps    + Confronta
ultra 1920x1080
12.4  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
basso 1024x768
12.1  fps    + Confronta
medio 1366x768
9.2  fps    + Confronta
alto 1366x768
5.2  fps    + Confronta
ultra 1920x1080
2.3  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
GRID 2

GRID 2

2013
basso 1024x768
34.4  fps    + Confronta
medio 1366x768
25.7  fps    + Confronta
alto 1366x768
18  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
13.2  fps    + Confronta
medio 1366x768
10  fps    + Confronta
alto 1366x768
4.8  fps    + Confronta
ultra 1920x1080
2.6  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1280x720
45.4  fps    + Confronta
medio 1366x768
20.1  fps    + Confronta
alto 1366x768
17.4  fps    + Confronta
ultra 1920x1080
4.4  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
basso 1024x768
146  fps    + Confronta
medio 1366x768
44  fps    + Confronta
alto 1366x768
24.1  fps    + Confronta
ultra 1920x1080
7.5  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli medio.
SimCity

SimCity

2013
basso 1024x768
27.4  fps    + Confronta
medio 1366x768
15.1  fps    + Confronta
alto 1366x768
11.2  fps    + Confronta
ultra 1920x1080
4.3  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
41  fps    + Confronta
medio 1366x768
20  fps    + Confronta
alto 1366x768
13.3  fps    + Confronta
ultra 1920x1080
4.4  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
basso 1024x768
76  fps    + Confronta
medio 1366x768
31.8  fps    + Confronta
alto 1366x768
23.4  fps    + Confronta
ultra 1920x1080
12.8  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
Far Cry 3

Far Cry 3

2012
basso 1024x768
25.1  fps    + Confronta
medio 1366x768
14.3  fps    + Confronta
alto 1366x768
5.1  fps    + Confronta
ultra 1920x1080
1.7  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
19.8  fps    + Confronta
medio 1366x768
18  fps    + Confronta
alto 1366x768
6.8  fps    + Confronta
ultra 1920x1080
3.5  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
49  fps    + Confronta
medio 1366x768
34  fps    + Confronta
alto 1366x768
15.6  fps    + Confronta
ultra 1920x1080
8 8.7 ~ 8 fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
Fifa 13

Fifa 13

2012
basso 1024x768
128  fps    + Confronta
medio 1366x768
86  fps    + Confronta
alto 1366x768
73  fps    + Confronta
ultra 1920x1080
45  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli ultra.
F1 2012

F1 2012

2012
basso 1024x768
45  fps    + Confronta
medio 1366x768
32  fps    + Confronta
alto 1366x768
28  fps    + Confronta
ultra 1920x1080
12  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
basso 1024x768
82  fps    + Confronta
medio 1366x768
73  fps    + Confronta
alto 1366x768
50  fps    + Confronta
ultra 1920x1080
27.1  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli alto.
basso 1024x768
58  fps    + Confronta
medio 1366x768
37  fps    + Confronta
alto 1366x768
32  fps    + Confronta
ultra 1920x1080
20  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli medio.
basso 1280x720
34.5  fps    + Confronta
medio 1366x768
24.2  fps    + Confronta
alto 1366x768
16.1  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
basso 1024x768
21.1  fps    + Confronta
medio 1366x768
14.2  fps    + Confronta
alto 1366x768
10.9  fps    + Confronta
ultra 1920x1080
3.7  fps    + Confronta
» Il Benchmark indica che il gioco non è utilizzabile con i settaggi testati.
Sims 3

Sims 3

2009
basso 800x600
117  fps    + Confronta
medio 1024x768
58  fps    + Confronta
alto 1280x1024
32.3  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli medio.
Supreme Commander - FA Bench

Supreme Commander - FA Bench

2007
basso 1024x768
52.3  fps    + Confronta
medio 1024x768
34.7  fps    + Confronta
alto 1024x768
31.5  fps    + Confronta
ultra 1920x1080
16  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli basso.
World of Warcraft

World of Warcraft

2005
medio 1024x768
64  fps    + Confronta
ultra 1920x1080
9.7  fps    + Confronta
» Giocabile con tutti i portatili testati con dettagli medio.
bassomedioaltoultraQHD4K
The Witcher 39.5
Dirt Rally7221.312.5
Evolve10.7
Assassin´s Creed IV: Black Flag19.415.5
X-Plane 10.2543.717.67.65.1
Call of Duty: Ghosts30.919.67.6
Battlefield 426.518.412.73.9
Batman: Arkham Origins4024125
F1 201342302612
Fifa 147045.5
Total War: Rome II27.92216.72.8
Saints Row IV19.317.2104.9
The Bureau: XCOM Declassified29.415.17.14.2
Splinter Cell: Blacklist24.9234.70
Dota 252.52812.4
Company of Heroes 212.19.25.22.3
GRID 234.425.718
Metro: Last Light13.2104.82.6
BioShock Infinite45.420.117.44.4
StarCraft II: Heart of the Swarm1464424.17.5
SimCity27.415.111.24.3
Tomb Raider412013.34.4
Dead Space 37631.823.412.8
Far Cry 325.114.35.11.7
Hitman: Absolution19.8186.83.5
Call of Duty: Black Ops 2493415.68
Fifa 13128867345
F1 201245322812
Counter-Strike: GO82735027.1
Diablo III58373220
The Elder Scrolls V: Skyrim34.524.216.1
Battlefield 321.114.210.93.7
Sims 31175832.3
Supreme Commander - FA Bench52.334.731.516
World of Warcraft649.7
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
14
13
4
2
21
8
3
24
4
2
24
2







Per conoscere altri giochi che potrebbero essere utilizzabili e per una lista completa di tutti i giochi e delle schede grafiche visitate la nostra Gaming List

v1.26
log 05. 13:39:18

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Mon, 04 Mar 2024 05:34:43 +0100 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.036s ... 0.037s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.037s

#5 composed specs +0s ... 0.037s

#6 did output specs +0s ... 0.037s

#7 start showIntegratedCPUs +0s ... 0.037s

#8 getting avg benchmarks for device 4066 +0.03s ... 0.068s

#9 got single benchmarks 4066 +0.01s ... 0.078s

#10 got avg benchmarks for devices +0s ... 0.078s

#11 min, max, avg, median took s +0.455s ... 0.532s

#12 before gaming benchmark output +0s ... 0.532s

#13 Got 123 rows for game benchmarks. +0.004s ... 0.536s

#14 composed SQL query for gamebenchmarks +0s ... 0.536s

#15 got data and put it in $dataArray +0.025s ... 0.561s

#16 benchmarks composed for output. +1.114s ... 1.675s

#17 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.678s

#18 return log +0s ... 1.678s

Nessuna recensione trovato per questa scheda grafica

Please share our article, every link counts!

Classe 1

NVIDIA RTX A6000 Desktop
Radeon Pro W6800 Desktop
Radeon RX 6800 Desktop
NVIDIA Titan RTX Desktop
Radeon RX 6750 XT Desktop
Radeon RX 6700 XT Desktop
Radeon RX 6650 XT Desktop

Classe 2

NVIDIA GeForce RTX 3060 Desktop
Titan X Pascal Desktop
Radeon VII Desktop
Radeon RX 5700 XT (Desktop) Desktop
Radeon RX 5700 (Desktop) Desktop
RX Vega 56 Desktop
Radeon RX 5600 XT (Desktop) Desktop
Pro Vega 56 Desktop
GeForce GTX 1650 Super (Desktop) Desktop
Radeon RX 580 Desktop
GeForce GTX 1060 (Desktop) Desktop
Radeon RX 570 Desktop
Radeon RX 480 Desktop

Classe 3

UHD Graphics 32EUs
UHD Graphics 750
FirePro W4100 Desktop
FirePro W2100 Desktop

Classe 4

UHD Graphics 730

Posizione approssimativa dell'adattatore grafico
