Intel Celeron N3160

Intel N3160

L'Intel Celeron N3160 è un SoC quad-core per portatili entry-level, annunziato ad inizio 2016. Ha un clock da 1.6 - 2.24 GHz (Burst) e fa parte della piattaforma Braswell. E' realizzato con un moderno processo da 14-nm (P1273) con FinFETs. In aggiunta ai quattro CPU cores, il SoC offre una GPU DirectX 11.2-capable ed un controller di memoria DDR3L (2x 64 bit, 25.6 GB/s). Rispetto al predecessore Celeron N3150, l'N3160 ha un Burst clock superiore di 160 MHz.

Architettura

I processor cores si basano sull'architettura Airmont, che di base è una modifica del precedente core Silvermont. Mentre le prestazioni per clock non sono migliorate, il processo più efficiente da 14 nm può comportare un miglior utilizzo del CPU Burst (alias Turbo Boost) e di conseguenza prestazioni leggermente migliori in alcune situazioni. Le prestazioni per-MHz sono ancora molto più basse rispetto alle più costose Core series (i.e. Broadwell).

Performance

Con 4 CPU cores ed un clock tra 1.6-2.24 GHz, le specifiche tenciche sono simili al precedente Celeron N2930, quindi il processore ha prestazioni performance appena migliori. Questo significa che il processore è adatto alle applicazioni quotidiane (ufficio, browsing) ed anche un leggero multi-tasking non dovrebbe rappresentare un problema.

Grafica

L'HD Graphics (Braswell) si basa sull'architettura Intel Gen8, che supporta DirectX 11.2 e si trova anche sulle serie Broadwell (i.e. HD Graphics 5300). Con 12 EUs (Execution Units) ed una velocità clock fino a 640 MHz, tuttavia, le performance della GPU sono molto più basse. In media, la GPU è veloce il doppio rispetto ad una HD Graphics (Bay Trail), quindi è poco più lenta rispetto alla vecchia HD Graphics 4000. Solo i giochi datati come Counter Strike: GO saranno fluidi. Il chip comprende ancora una unità video avanzata con supporto per accelerazione video 4K/H.265.

Consumo Energetico

L'intero SoC ha un TDP da 6 watts (SDP 4 watts). Pertanto, il chip di solito può essere raffreddato passivamente.

SerieIntel Celeron
Nome in codiceBraswell

Serie: Celeron Braswell

Intel Celeron N3160 « 1.6 - 2.24 GHz4 / 4 cores
Intel Celeron N31501.6 - 2.08 GHz4 / 4 cores
Intel Celeron N30601.6 - 2.48 GHz2 / 2 cores
Intel Celeron N30501.6 - 2.16 GHz2 / 2 cores
Intel Celeron N30001.04 - 2.08 GHz2 / 2 cores
Clock Rate1600 - 2240 MHz
Level 2 Cache2 MB
Numero di Cores / Threads4 / 4
Consumo energetico (TDP = Thermal Design Power)6 Watt
Tecnologia del produttore14 nm
Temperatura massima90 °C
SocketFCBGA1170
FeaturesIntel HD Graphics (Braswell, 12 EUs, 320 - 640 MHz), Wireless Display, Quick Sync, AES-NI, max. 8 GB Dual-Channel DDR3L-1600 (25,6 GB/s), 5x USB 3.0, 4x PCIe 2.0, 2x SATA 6.0 Gbit/s
GPUIntel HD Graphics (Braswell) (320 - 640 MHz)
64 BitSupporto 64 Bit
Architecturex86
Data di annuncio04/01/2016
Collegamento Prodotto (esterno)ark.intel.com

Benchmark

3DMark - 3DMark Ice Storm Unlimited Physics
19687 Points (17%)
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Physics
1696 Points (19%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
1091 punti (11%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
3305 punti (4%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
4300 ms (5%)
Sunspider - Sunspider 1.0 Total Score *
991 ms (11%)
Octane V2 - Octane V2 Total Score
8018 Points (7%)
PCMark for Android - PCM f. Android Computer Vision
3380 Points (18%)
PCMark for Android - PCM f. Android Storage
7992 Points (17%)
PCMark for Android - PCM f. Android Work Score
7580 Points (38%)
- Valori di benchmark per questa scheda grafica
- Valori medi di benchmark per questa scheda grafica
* Numeri più piccoli rappresentano prestazioni supeiori

v1.26
log 16. 15:14:02

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Sat, 16 Mar 2024 05:37:00 +0100 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.006s ... 0.007s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#7 composed specs +0s ... 0.008s

#8 did output specs +0s ... 0.008s

#9 getting avg benchmarks for device 8167 +0.003s ... 0.011s

#10 got single benchmarks 8167 +0.016s ... 0.027s

#11 got avg benchmarks for devices +0s ... 0.027s

#12 min, max, avg, median took s +0.216s ... 0.243s

#13 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.243s

#14 return log +0s ... 0.243s

Recensioni per il Intel Celeron N3160 processore

Recensione del Convertibile Acer Chromebook R 11 (N3160, eMMC, HD)

Recensione del Convertibile Acer Chromebook R 11 (N3160, eMMC, HD)

Acer’s 11.6-inch Chromebook convertible offers a touch-enabled IPS display and silent operation. Thanks to the inclusion of the Google Play Store, users can in...
Intel Celeron N3160 | Intel HD Graphics 400 (Braswell) | 11.60" | 1.3 kg

Lenovo N23 Ruggedized 80YS0044NH: Intel HD Graphics (Braswell), 11.60", 1.3 kg
  Recensioni esterne » Lenovo N23 Ruggedized 80YS0044NH

Acer Chromebook 15 CB3-532-C8E0: Intel HD Graphics 400 (Braswell), 15.60", 2 kg
  Recensioni esterne » Acer Chromebook 15 CB3-532-C8E0

Acer Extensa 2519-C7L5: Intel HD Graphics (Braswell), 15.60", 2 kg
  Recensioni esterne » Acer Extensa 2519-C7L5

Acer Chromebook R11 CB5-132T-C9KK: Intel HD Graphics (Braswell), 11.60", 1.3 kg
  Recensioni esterne » Acer Chromebook R11 CB5-132T-C9KK

Lenovo Ideapad 110-15IBR-80T700JXSP: Intel HD Graphics (Braswell), 15.60", 2.3 kg
  Recensioni esterne » Lenovo Ideapad 110-15IBR-80T700JXSP

Acer Chromebook 14 CB3-431-C8YS: Intel HD Graphics (Braswell), 14.00", 1.7 kg
  Recensioni esterne » Acer Chromebook 14 CB3-431-C8YS

Acer Chromebook 11 N7 C731-C28L: Intel HD Graphics (Braswell), 11.60", 1.3 kg
  Recensioni esterne » Acer Chromebook 11 N7 C731-C28L

Acer Chromebook 14 CB3-431-C0AK: Intel HD Graphics 400 (Braswell), 14.00", 1.5 kg
  Recensioni esterne » Acer Chromebook 14 CB3-431-C0AK

Acer Aspire R3-131T-C7X1: Intel HD Graphics 400 (Braswell), 11.60", 1.5 kg
  Recensioni esterne » Acer Aspire R3-131T-C7X1

Acer Chromebook 14 CB3-431-C5K7: Intel HD Graphics (Braswell), 14.00", 1.7 kg
  Recensioni esterne » Acer Chromebook 14 CB3-431-C5K7

Acer Chromebook 14 CB3-431-C6UD: Intel HD Graphics 400 (Braswell), 14.00", 1.6 kg
  Recensioni esterne » Acer Chromebook 14 CB3-431-C6UD
