Recensione breve della Workstation HP ZBook 15u G4 (7500U, FirePro W4190M)

Benjamin Herzig (traduzione a cura di G. De Luca), 10/06/2017

Ultrabook o workstation. La ZBook 15u G4 è una workstation mobile realizzata da HP che - sebbene più economica rispetto ai suoi fratelli - riesce a rispecchiare gli elevati standards di qualità ZBook. Sfortunatamente, questa sottile e leggera workstation ha anche hardware dalle prestazioni basse. Vediamo se questo concept lavora o meno secondo le aspettative nella nostra recensione.

HP ZBook 15u G4
Scheda grafica
AMD FirePro W4190M - 2048 MB, Core: 825 MHz, Memoria: 1000 MHz, GDDR5 Speicher, 16.40.2902, Switchable Graphics
Memoria
16384 MB
, DDR4-2133
Schermo
15.6 pollici 16:9, 1920x1080 pixel 141 PPI, LP156WF6, IPS LED, lucido: no
Scheda madre
Intel Kaby Lake-U Premium PCH
Harddisk
Samsung SM961 MZVKW512HMJP m.2 PCI-e, 512 GB
, 411 GB libera
Scheda audio
Intel Kaby Lake-U/Y PCH - High Definition Audio
Porte di connessione
3 USB 3.0 / 3.1, 1 VGA, 1 DisplayPort, 1 Kensington Lock, 1 Porta Docking, Connessioni Audio: Kombo-Audio, Lettore schede: SD-Kartenleser, 1 SmartCard, 1 Lettore impronte digitali, NFC
Rete
Intel Ethernet Connection I219-V (10/100/1000MBit), Intel Dual Band Wireless-AC 8265 (a/b/g/n/ac), Bluetooth 4.2
Dimensioni
altezza x larghezza x profondità (in mm): 20 x 383 x 258
Batteria
51 Wh polimeri di litio
Sistema Operativo
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: 720p
Altre caratteristiche
Casse: Stereo-Lautsprecher, Tastiera: 6 Reihen Chiclet, Illuminazione Tastiera: si, 65 W Netzteil, Treiber-CD, Microsoft Office Trial, HP WorkWise, HP Sure Connect, HP Notifications, HP Client Security Manager, HP Performance Advisor, HP Support Assistant, 36 Mesi Garanzia
Peso
1.9 kg, Alimentazione: 280 gr
Prezzo
2239 Euro



Size Comparison

Left: Kensington lock, VGA, USB 3.0 Type-A, smart-card reader
Left: Kensington lock, VGA, USB 3.0 Type-A, smart-card reader
Right: USB 3.1 Gen 1 Type-C, DisplayPort, SD-card reader, audio combo, USB  3.0 Type-A, ethernet, docking port, SIM slot, power
Right: USB 3.1 Gen 1 Type-C, DisplayPort, SD-card reader, audio combo, USB 3.0 Type-A, ethernet, docking port, SIM slot, power
SDCardreader Transfer Speed
average JPG Copy Test (av. of 3 runs)
HP ZBook Studio G4-Y6K17EA
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
185 MB/s ∼100% +137%
Dell Precision 5520 UHD
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
157.5 MB/s ∼85% +101%
HP ZBook 15u G4
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
78.2 MB/s ∼42%
Lenovo ThinkPad P51s 20HB000SGE
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
76.8 MB/s ∼42% -2%
maximum AS SSD Seq Read Test (1GB)
Dell Precision 5520 UHD
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
254.5 MB/s ∼100% +193%
HP ZBook Studio G4-Y6K17EA
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
210.7 MB/s ∼83% +143%
Lenovo ThinkPad P51s 20HB000SGE
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
89 MB/s ∼35% +3%
HP ZBook 15u G4
(Toshiba Exceria Pro SDXC 64 GB UHS-II)
86.8 MB/s ∼34%
Networking
iperf3 Client (receive) TCP 1 m 4M x10
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Broadcom BCM15700A2 802.11ac
949 MBit/s ∼100% +84%
Lenovo ThinkPad P51s 20HB000SGE
Intel Dual Band Wireless-AC 8265
672 MBit/s ∼71% +30%
HP ZBook Studio G4-Y6K17EA
Intel Dual Band Wireless-AC 8265
632 MBit/s ∼67% +23%
Dell Precision 5520 UHD
Intel Dual Band Wireless-AC 8265
622 MBit/s ∼66% +21%
HP ZBook 15u G4
Intel Dual Band Wireless-AC 8265
515 MBit/s ∼54%
iperf3 Client (transmit) TCP 1 m 4M x10
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Broadcom BCM15700A2 802.11ac
845 MBit/s ∼100% +67%
Lenovo ThinkPad P51s 20HB000SGE
Intel Dual Band Wireless-AC 8265
508 MBit/s ∼60% 0%
Dell Precision 5520 UHD
Intel Dual Band Wireless-AC 8265
506 (min: 622) MBit/s ∼60% 0%
HP ZBook 15u G4
Intel Dual Band Wireless-AC 8265
506 MBit/s ∼60%
HP ZBook Studio G4-Y6K17EA
Intel Dual Band Wireless-AC 8265
480 MBit/s ∼57% -5%
298
cd/m²
299
cd/m²
298
cd/m²
322
cd/m²
320
cd/m²
316
cd/m²
323
cd/m²
302
cd/m²
308
cd/m²
Distribuzione della luminosità
X-Rite i1Pro 2
Massima: 323 cd/m² Media: 309.6 cd/m² Minimum: 10 cd/m²
Distribuzione della luminosità: 92 %
Al centro con la batteria: 318 cd/m²
Contrasto: 711:1 (Nero: 0.45 cd/m²)
ΔE Color 5.5 | - Ø
ΔE Greyscale 4.8 | - Ø
83.8% sRGB (Argyll) 55% AdobeRGB 1998 (Argyll)
Gamma: 2.28
HP ZBook 15u G4
LP156WF6, , 1920x1080, 15.6
Lenovo ThinkPad P51s 20HB000SGE
BOE NV156QUM-N44, , 3840x2160, 15.6
Dell Precision 5520 UHD
SHP1476, , 3840x2160, 15.6
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
APPA031, , 2880x1800, 15.4
HP ZBook Studio G4-Y6K17EA
SHP1445, , 3840x2160, 15.6
HP ZBook 15u G3
CMN15C3, , 1920x1080, 15.6
Response Times
-35%
-69%
132%
-47%
-57%
Response Time Grey 50% / Grey 80% *
39.6 (22.4, 17.2)
38.4 (20.4, 18)
3%
59.2 (27.6, 31.6)
-49%
48 (23.6, 24.4)
-21%
44.8 (22, 22.8)
-13%
45.6 (25.6, 20)
-15%
Response Time Black / White *
22 (12, 10)
24.8 (13.6, 11.2)
-13%
41.6 (26.8, 14.8)
-89%
33.8 (19.6, 14.2)
-54%
30 (17.2, 12.8)
-36%
34.4 (16.4, 18)
-56%
PWM Frequency
20830 (90)
980.4 (90)
-95%
119000 (80, 210)
471%
1497 (50)
-93%
198.4 (90)
-99%
Screen
15%
16%
45%
34%
-39%
Brightness
310
290
-6%
368
19%
523
69%
338
9%
284
-8%
Brightness Distribution
92
85
-8%
90
-2%
86
-7%
78
-15%
89
-3%
Black Level *
0.45
0.32
29%
0.48
-7%
0.44
2%
0.3
33%
0.849
-89%
Contrast
711
991
39%
776
9%
1239
74%
1080
52%
351
-51%
Colorchecker DeltaE2000 *
5.5
3.6
35%
2.6
53%
1.6
71%
1.6
71%
8.68
-58%
Greyscale DeltaE2000 *
4.8
4.2
12%
3.7
23%
1.9
60%
2.5
48%
9.3
-94%
Gamma
2.28 105%
2.24 107%
2.14 112%
2.26 106%
2.21 109%
2.27 106%
CCT
6987 93%
6740 96%
7096 92%
6834 95%
6273 104%
10585 61%
Color Space (Percent of AdobeRGB 1998)
55
59.5
8%
63
15%
85.7
56%
50.99
-7%
Color Space (Percent of sRGB)
83.8
91.1
9%
99
18%
98.9
18%
80.42
-4%
Media totale (Programma / Settaggio)
-10% / 1%
-27% / -1%
89% / 74%
-7% / 12%
-48% / -44%

* ... Meglio usare valori piccoli

Outdoors in the shade
Outdoors in the shade
Outdoors in sunlight
Outdoors in sunlight

Tempi di risposta del Display

I tempi di risposta del display mostrano quanto sia veloce lo schermo a cambaire da un colore all'altro. Tempi di risposta lenti poccono creare sovrapposizioni negloi oggetti in movimento. Specialmente i giocatori patiti del 3D dovrebbero usare uno schermo con rempi di risposta bassi.
       Tempi di risposta dal Nero al Bianco
22 ms ... rise ↗ and fall ↘ combined↗ 12 ms Incremento
↘ 10 ms Calo
Lo schermo mostra buoni tempi di risposta durante i nostri tests, ma potrebbe essere troppo lento per i gamers competitivi.
In comparison, all tested devices range from 0.8 (minimum) to 240 (maximum) ms. » 17 % of all devices are better.
This means that the measured response time is better than the average of all tested devices (26.6 ms).
       Tempo di risposta dal 50% Grigio all'80% Grigio
39.6 ms ... rise ↗ and fall ↘ combined↗ 22.4 ms Incremento
↘ 17.2 ms Calo
Lo schermo mostra tempi di risposta lenti nei nostri tests e sarà insoddisfacente per i gamers.
In comparison, all tested devices range from 0.9 (minimum) to 636 (maximum) ms. » 42 % of all devices are better.
This means that the measured response time is similar to the average of all tested devices (42.7 ms).

Screen Flickering / PWM (Pulse-Width Modulation)

To dim the screen, some notebooks will simply cycle the backlight on and off in rapid succession - a method called Pulse Width Modulation (PWM) . This cycling frequency should ideally be undetectable to the human eye. If said frequency is too low, users with sensitive eyes may experience strain or headaches or even notice the flickering altogether.
Screen flickering / PWM detected 20830 Hz90 % brightness setting

The display backlight flickers at 20830 Hz (Likely utilizing PWM) Flickering detected at a brightness setting of 90 % and below. There should be no flickering or PWM above this brightness setting.

The frequency of 20830 Hz is quite high, so most users sensitive to PWM should not notice any flickering.

In comparison: 56 % of all tested devices do not use PWM to dim the display. If PWM was detected, an average of 7168 (minimum: 43 - maximum: 142900) Hz was measured.

HWiNFO
HWiNFO
CPU-Z
CPU-Z
CPU-Z Caches
CPU-Z Caches
CPU-Z Mainboard
CPU-Z Mainboard
CPU-Z Memory
CPU-Z Memory
CPU-Z  SPD
CPU-Z SPD
GPU-Z Intel HD Graphics 620
GPU-Z Intel HD Graphics 620
LatencyMon
LatencyMon
0102030405060708090100110120130140150160170180190200210220230240250260270280290300310320330340350360Tooltip
Cinebench R15 CPU Multi 64 Bit
Cinebench R15
CPU Single 64Bit
Dell Precision 5520 UHD
Intel Xeon E3-1505M v6
170 Points ∼100% +16%
HP ZBook Studio G4-Y6K17EA
Intel Xeon E3-1505M v6
170 Points ∼100% +16%
Lenovo ThinkPad P51s 20HB000SGE
Intel Core i7-7600U
162 Points ∼95% +10%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Intel Core i7-7700HQ
159.95 Points ∼94% +9%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Intel Core i7-7700HQ
156 Points ∼92% +6%
HP ZBook 15u G4
Intel Core i7-7500U
147 Points ∼86%
HP ZBook 15u G3
Intel Core i7-6600U
143 Points ∼84% -3%
CPU Multi 64Bit
HP ZBook Studio G4-Y6K17EA
Intel Xeon E3-1505M v6
737 Points ∼100% +106%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Intel Core i7-7700HQ
732 (min: 729) Points ∼99% +105%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Intel Core i7-7700HQ
726.78 (min: 704.77) Points ∼99% +104%
Dell Precision 5520 UHD
Intel Xeon E3-1505M v6
654 Points ∼89% +83%
Lenovo ThinkPad P51s 20HB000SGE
Intel Core i7-7600U
379 Points ∼51% +6%
HP ZBook 15u G4
Intel Core i7-7500U
357 Points ∼48%
HP ZBook 15u G3
Intel Core i7-6600U
330 Points ∼45% -8%
Cinebench R15 Ref. Match 64Bit
98 %
Cinebench R15 OpenGL 64Bit
48.99 fps
Cinebench R15 CPU Multi 64Bit
357 Points
Cinebench R15 CPU Single 64Bit
147 Points
Aiuto
PCMark 8
Work Score Accelerated v2
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
5100 Points ∼100%
HP ZBook 15u G3
FirePro W4190M, 6600U, Samsung SM951 MZVPV256HDGL m.2 PCI-e
4900 Points ∼96% -4%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
4648 Points ∼91% -9%
HP ZBook Studio G4-Y6K17EA
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
4408 Points ∼86% -14%
Dell Precision 5520 UHD
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
4291 Points ∼84% -16%
Lenovo ThinkPad P51s 20HB000SGE
Quadro M520, 7600U, Samsung SSD PM961 1TB M.2 PCIe 3.0 x4 NVMe (MZVLW1T0)
4193 Points ∼82% -18%
Home Score Accelerated v2
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
4169 Points ∼100%
HP ZBook Studio G4-Y6K17EA
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
4093 Points ∼98% -2%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
4054 Points ∼97% -3%
HP ZBook 15u G3
FirePro W4190M, 6600U, Samsung SM951 MZVPV256HDGL m.2 PCI-e
3974 Points ∼95% -5%
Dell Precision 5520 UHD
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
3504 Points ∼84% -16%
Lenovo ThinkPad P51s 20HB000SGE
Quadro M520, 7600U, Samsung SSD PM961 1TB M.2 PCIe 3.0 x4 NVMe (MZVLW1T0)
3232 Points ∼78% -22%
PCMark 10
Digital Content Creation
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
3999 Points ∼100% +46%
HP ZBook Studio G4-Y6K17EA
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
3926 Points ∼98% +44%
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
2734 Points ∼68%
Productivity
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
7201 Points ∼100%
HP ZBook Studio G4-Y6K17EA
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
6561 Points ∼91% -9%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
5765 Points ∼80% -20%
Essentials
HP ZBook Studio G4-Y6K17EA
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
8514 Points ∼100% +11%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
8250 Points ∼97% +8%
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
7673 Points ∼90%
Score
HP ZBook Studio G4-Y6K17EA
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
4323 Points ∼100% +13%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
4122 Points ∼95% +8%
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
3818 Points ∼88%
PCMark 8 Home Score Accelerated v2
4169 punti
PCMark 8 Creative Score Accelerated v2
5127 punti
PCMark 8 Work Score Accelerated v2
5100 punti
Aiuto
HP ZBook 15u G4
Samsung SM961 MZVKW512HMJP m.2 PCI-e
Lenovo ThinkPad P51s 20HB000SGE
Samsung SSD PM961 1TB M.2 PCIe 3.0 x4 NVMe (MZVLW1T0)
Dell Precision 5520 UHD
Samsung SM961 MZVKW512HMJP m.2 PCI-e
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Apple SSD SM0256L
HP ZBook Studio G4-Y6K17EA
Samsung SM961 MZVKW512HMJP m.2 PCI-e
HP ZBook 15u G3
Samsung SM951 MZVPV256HDGL m.2 PCI-e
CrystalDiskMark 3.0
3%
9%
-10%
7%
13%
Write 4k QD32
478.3
548.6
15%
506.1
6%
468.37
-2%
595.1
24%
382.2
-20%
Read 4k QD32
551.8
641.7
16%
633.1
15%
630.82
14%
645.3
17%
584.9
6%
Write 4k
152.7
161.4
6%
169.4
11%
12.87
-92%
182
19%
136.9
-10%
Read 4k
53.35
54.8
3%
56.08
5%
10.76
-80%
56.54
6%
51.94
-3%
Write 512
1535
959.4
-37%
1611
5%
1124.03
-27%
1279
-17%
1240
-19%
Read 512
413.4
782.1
89%
459.1
11%
967.57
134%
391.4
-5%
1216
194%
Write Seq
1580
1138
-28%
1662
5%
1505.1
-5%
1562
-1%
1247
-21%
Read Seq
2042
1189
-42%
2253
10%
1556.5
-24%
2229
9%
1617
-21%
Samsung SM961 MZVKW512HMJP m.2 PCI-e
Sequential Read: 2042 MB/s
Sequential Write: 1580 MB/s
512K Read: 413.4 MB/s
512K Write: 1535 MB/s
4K Read: 53.35 MB/s
4K Write: 152.7 MB/s
4K QD32 Read: 551.8 MB/s
4K QD32 Write: 478.3 MB/s
3DMark 11 - 1280x720 Performance GPU
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
5515 Points ∼100% +132%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
5185 Points ∼94% +118%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
5105 Points ∼93% +115%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
2658 Points ∼48% +12%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
2379 Points ∼43%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
1932 Points ∼35% -19%
3DMark
1920x1080 Fire Strike Graphics
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
4165 Points ∼100% +131%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
4118 Points ∼99% +128%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
3721 Points ∼89% +106%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
2342 Points ∼56% +30%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
1806 Points ∼43%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
1588 Points ∼38% -12%
1280x720 Cloud Gate Standard Graphics
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
28254 Points ∼100% +124%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
26860 Points ∼95% +113%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
22624 Points ∼80% +80%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
13394 Points ∼47% +6%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
12601 Points ∼45%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
8513 Points ∼30% -32%
SPECviewperf 12
1900x1060 Solidworks (sw-03)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
78.37 fps ∼100% +160%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
69.01 fps ∼88% +129%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
48.83 fps ∼62% +62%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
48.8 fps ∼62% +62%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
45.9 fps ∼59% +52%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
31.41 fps ∼40% +4%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
30.12 fps ∼38%
1900x1060 Siemens NX (snx-02)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
34.66 fps ∼100% +74%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
34.18 fps ∼99% +72%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
24.13 fps ∼70% +21%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
19.91 fps ∼57%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
19.89 fps ∼57% 0%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
14.2 fps ∼41% -29%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
14.17 fps ∼41% -29%
1900x1060 Showcase (showcase-01)
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
26.2 fps ∼100% +157%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
22.17 fps ∼85% +117%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
19.9 fps ∼76% +95%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
19.86 fps ∼76% +95%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
11.8 fps ∼45% +16%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
10.21 fps ∼39%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
4.98 fps ∼19% -51%
1900x1060 Medical (medical-01)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
17.77 fps ∼100% +294%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
17.49 fps ∼98% +288%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
9.1 fps ∼51% +102%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
9.06 fps ∼51% +101%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
8.29 fps ∼47% +84%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
6.09 fps ∼34% +35%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
4.51 fps ∼25%
1900x1060 Maya (maya-04)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
37.29 fps ∼100% +124%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
32.07 fps ∼86% +92%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
30.54 fps ∼82% +83%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
30.5 fps ∼82% +83%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
19.51 fps ∼52% +17%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
16.66 fps ∼45%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
16.38 fps ∼44% -2%
1900x1060 Energy (energy-01)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
3.85 fps ∼100% +1032%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
3.78 fps ∼98% +1012%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
0.53 fps ∼14% +56%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
0.41 fps ∼11% +21%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
0.34 fps ∼9%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
0.32 fps ∼8% -6%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
0.32 fps ∼8% -6%
1900x1060 Creo (creo-01)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
46.97 fps ∼100% +178%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
46.12 fps ∼98% +173%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
33.4 fps ∼71% +98%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
33.39 fps ∼71% +98%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
27.98 fps ∼60% +66%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
16.87 fps ∼36% 0%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
16.87 fps ∼36%
1900x1060 Catia (catia-04)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
45.86 fps ∼100% +153%
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
45.75 fps ∼100% +152%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
30.8 fps ∼67% +70%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
30.79 fps ∼67% +70%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
26.22 fps ∼57% +45%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
18.62 fps ∼41% +3%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
18.13 fps ∼40%
1900x1060 3ds Max (3dsmax-05)
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
26.74 fps ∼100% +134%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
26.7 fps ∼100% +134%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
19.73 fps ∼74% +73%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
11.42 fps ∼43%
SiSoft Sandra 2016
Image Processing
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
191.42 MPix/s ∼100%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
149.34 MPix/s ∼78% -22%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
140.2 MPix/s ∼73% -27%
GP Cryptography (Higher Security AES256+SHA2-512)
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
8 GB/s ∼100% +104%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
4.86 GB/s ∼61% +24%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
3.92 GB/s ∼49%
GP Financial Analysis (FP High/Double Precision)
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
42 KOPT/s ∼100%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
19.32 KOPT/s ∼46% -54%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
14 KOPT/s ∼33% -67%
Unigine Valley 1.0
1920x1080 Extreme HD DirectX AA:x8
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
27.7 fps ∼100% +347%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
16 (min: 9) fps ∼58% +158%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
11.4 fps ∼41% +84%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
6.2 fps ∼22%
1920x1080 Extreme HD Preset OpenGL AA:x8
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
23.9 fps ∼100% +185%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ (OS X)
16.1 (min: 16) fps ∼67% +92%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
9.9 fps ∼41% +18%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
8.4 fps ∼35%
Unigine Heaven 4.0
Extreme Preset OpenGL
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
9.9 fps ∼100% +32%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
7.5 fps ∼76%
Extreme Preset DX11
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ (Win 10)
20.4 (min: 7) fps ∼100% +132%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
10.6 fps ∼52% +20%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
8.8 fps ∼43%
LuxMark v2.0 64Bit
Room GPUs-only
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
979 Samples/s ∼100% +127%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
656 Samples/s ∼67% +52%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
506 Samples/s ∼52% +17%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
431 Samples/s ∼44%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
405 Samples/s ∼41% -6%
Sala GPUs-only
Dell Precision 5520 UHD
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
1562 Samples/s ∼100% +59%
HP ZBook 15u G3
AMD FirePro W4190M, Intel Core i7-6600U
1034 Samples/s ∼66% +5%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
AMD Radeon Pro 555, Intel Core i7-7700HQ
1001 Samples/s ∼64% +2%
HP ZBook 15u G4
AMD FirePro W4190M, Intel Core i7-7500U
984 Samples/s ∼63%
HP ZBook Studio G4-Y6K17EA
NVIDIA Quadro M1200, Intel Xeon E3-1505M v6
852 Samples/s ∼55% -13%
Lenovo ThinkPad P51s 20HB000SGE
NVIDIA Quadro M520, Intel Core i7-7600U
708 Samples/s ∼45% -28%
3DMark 11 Performance
2611 punti
3DMark Cloud Gate Standard Score
7894 punti
3DMark Fire Strike Score
1711 punti
Aiuto
01234567Tooltip
The Witcher 3 ultra
BioShock Infinite - 1920x1080 Ultra Preset, DX11 (DDOF)
Dell Precision 5520 UHD
Quadro M1200, E3-1505M v6, Samsung SM961 MZVKW512HMJP m.2 PCI-e
47 fps ∼100% +204%
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
Radeon Pro 555, 7700HQ, Apple SSD SM0256L
37.6 (min: 11) fps ∼80% +143%
Lenovo ThinkPad P51s 20HB000SGE
Quadro M520, 7600U, Samsung SSD PM961 1TB M.2 PCIe 3.0 x4 NVMe (MZVLW1T0)
24.2 fps ∼51% +57%
Lenovo ThinkPad T570-20HAS01E00
GeForce 940MX, 7500U, Samsung PM961 NVMe MZVLW512HMJP
21.5 fps ∼46% +39%
HP ZBook 15u G4
FirePro W4190M, 7500U, Samsung SM961 MZVKW512HMJP m.2 PCI-e
15.45 fps ∼33%
HP ZBook 15u G3
FirePro W4190M, 6600U, Samsung SM951 MZVPV256HDGL m.2 PCI-e
13.64 fps ∼29% -12%
basso medio alto ultra
BioShock Infinite (2013) 101.9453.8946.8615.45fps
Company of Heroes 2 (2013) 39.3230.5117.17fps
The Witcher 3 (2015) 28.517.399.696fps

Rumorosità

Idle
29.5 / 29.5 / 30.5 dB(A)
Sotto carico
35 / 37.4 dB(A)



30 dB
silenzioso
40 dB(A)
udibile
50 dB(A)
rumoroso

min: dark, med: mid, max: light   Audix TM1, Arta (15 cm di distanza)   Rumorosità ambientale: 29.5 dB(A)
dB(A) 0102030405060708090Deep BassMiddle BassHigh BassLower RangeMidsHigher MidsLower HighsMid HighsUpper HighsSuper Highs2029.53027.826.329.929.328.82526.53028.926.729.128.927.33126.526.125.927.926.626.527.74025.625.727.125.626.927.523.75024.124.32424.426.324.623.16322.323.922.924.52524.7258022.124.723.823.924.625.523.91002122.622.821.122.622.52312521.222.421.721.422.6232116018.720.419.919.320.419.61920019.42020.318.819.719.819.42501919.618.71918.418.119.431518.719.418.918.317.91818.940017.819.517.91817.617.7195001819.418.117.617.216.919.463018.920.319.81917.516.521.180019.322.721.220.917.716.721.910002024.521.120.417.716.724.9125020.62523.222.618.817.324.4160021.326.624.222.918.917.526.2200021.326.224.123.11917.626.5250023.529.226.725.319.617.829.1315023.129.426.224.71918.129.1400020.126.222.921.618.317.825.8500018.622.820.319.51817.822.4630017.620.619.118.41817.420.2800017.118.918.218.118.217.318.41000016.517.917.317.617.416.617.8125001618.41817.718.216.117.71600015.818.218.718.918.715.616.9SPL32.537.53533.930.529.537.3N1.62.421.81.41.22.4median 19HP ZBook 15u G4median 20.6median 20.3median 19.3median 18.3median 17.6median 21Delta1.42.62.21.710.833529.231.334.8313534.43434.834.73334.43430.830.232.431.63431.230.930.832.529.631.228.928.529.129.328.128.927.128.626.929.72727.127.828.827.728.326.727.826.426.125.325.225.226.426.625.224.524.926.426.624.323.923.423.923.124.325.124.723.723.72425.126.125.222.622.621.926.125.323.32221.920.525.323.823.220.920.619.323.824.923.321.52018.924.925.223.422.319.718.125.225.923.421.619.41725.925.924.121.619.316.625.926.424.621.719.716.226.425.42421.318.216.625.424.923.62118.416.524.926.72421.417.915.926.730.827.723.319.216.330.832.528.523.919.716.632.527.524.820.517.916.327.522.921.218.617.416.922.920.819.618.217.31720.818.418.818.217.316.918.417.518.518.417.316.817.517.720.720.518.117.117.739.436.733.631.129.239.43.12.51.91.51.23.1median 25.3Lenovo ThinkPad P51s 20HB000SGEmedian 23.9median 21.6median 19.4median 17median 25.31.40.81.31.92.41.4hearing rangehide median Fan Noise
Carico massimo
 47.5 °C49.9 °C47.2 °C
 44.4 °C53.2 °C46.8 °C
 31.3 °C31 °C30.5 °C
Massima: 53.2 °C
Media: 42.4 °C
48.1 °C54 °C48.9 °C
44.7 °C47.1 °C46.4 °C
35.5 °C38.1 °C37.9 °C
Massima: 54 °C
Media: 44.5 °C
Alimentazione (max)  51.7 °C | Temperatura della stanza 22.4 °C | Voltcraft IR-900
dB(A) 0102030405060708090Deep BassMiddle BassHigh BassLower RangeMidsHigher MidsLower HighsMid HighsUpper HighsSuper Highs2035.629.335.62533.828.933.83132.826.532.84030.327.530.35029.424.629.46330.624.730.68033.425.533.410032.122.532.112536233616042.619.642.620047.419.847.425053.118.153.131555.41855.440057.817.757.850060.416.960.463062.516.562.580059.716.759.7100056.416.756.4125060.117.360.1160056.217.556.2200058.117.658.125006117.861315058.918.158.9400060.117.860.1500060.817.860.8630063.317.463.380006117.3611000056.216.656.21250056.116.156.1160005015.650SPL71.929.571.9N30.81.230.8median 57.8HP ZBook 15u G4median 17.6median 57.8Delta5.10.85.13338.432.739.329.63830.736.927.834.627.936.727.639.425.237.425.741.524.245.223.653.32262.621.462.520.35819.558.718.861.917.770.217.366.716.858.416.762.616.460.816.458.316.656.616.364.816.664.917.26317.157.617.156.91757.31754.129.675.21.336.9median 17.2Lenovo ThinkPad P51s 20HB000SGEmedian 58.42.34.5hearing rangehide median Pink Noise
HP ZBook 15u G4 audio analysis

(-) | not very loud speakers (71.9 dB)
Bass 100 - 315 Hz
(±) | reduced bass - on average 13.4% lower than median
(±) | linearity of bass is average (10.2% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 1.8% away from median
(±) | linearity of mids is average (7.1% delta to prev. frequency)
Highs 2 - 16 kHz
(+) | balanced highs - only 2.8% away from median
(+) | highs are linear (5.8% delta to prev. frequency)
Overall 100 - 16.000 Hz
(+) | overall sound is linear (13.5% difference to median)
Compared to same class
» 8% of all tested devices in this class were better, 8% similar, 83% worse
» The best had a delta of 13%, average was 20%, worst was 31%
Compared to all devices tested
» 12% of all tested devices were better, 3% similar, 85% worse
» The best had a delta of 3%, average was 21%, worst was 53%

Lenovo ThinkPad P51s 20HB000SGE audio analysis

(±) | speaker loudness is average but good (75.2 dB)
Bass 100 - 315 Hz
(±) | reduced bass - on average 10.7% lower than median
(±) | linearity of bass is average (11% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 3.9% away from median
(±) | linearity of mids is average (10.5% delta to prev. frequency)
Highs 2 - 16 kHz
(+) | balanced highs - only 3.1% away from median
(±) | linearity of highs is average (7.1% delta to prev. frequency)
Overall 100 - 16.000 Hz
(+) | overall sound is linear (12.9% difference to median)
Compared to same class
» 0% of all tested devices in this class were better, 8% similar, 92% worse
» The best had a delta of 13%, average was 20%, worst was 31%
Compared to all devices tested
» 10% of all tested devices were better, 2% similar, 88% worse
» The best had a delta of 3%, average was 21%, worst was 53%

Consumo di corrente
Off / Standbydarklight 0.29 / 0.47 Watt
Idledarkmidlight 3.85 / 7.5 / 11.8 Watt
Sotto carico midlight 47.7 / 90.2 Watt
 color bar
Leggenda: min: dark, med: mid, max: light        Metrahit Energy
HP ZBook 15u G4
7500U, FirePro W4190M, Samsung SM961 MZVKW512HMJP m.2 PCI-e, IPS LED, 1920x1080, 15.6
Lenovo ThinkPad P51s 20HB000SGE
7600U, Quadro M520, Samsung SSD PM961 1TB M.2 PCIe 3.0 x4 NVMe (MZVLW1T0), IPS, 3840x2160, 15.6
Dell Precision 5520 UHD
E3-1505M v6, Quadro M1200, Samsung SM961 MZVKW512HMJP m.2 PCI-e, IPS, 3840x2160, 15.6
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
7700HQ, Radeon Pro 555, Apple SSD SM0256L, IPS, 2880x1800, 15.4
HP ZBook Studio G4-Y6K17EA
E3-1505M v6, Quadro M1200, Samsung SM961 MZVKW512HMJP m.2 PCI-e, IPS, 3840x2160, 15.6
HP ZBook 15u G3
6600U, FirePro W4190M, Samsung SM951 MZVPV256HDGL m.2 PCI-e, TN LED, 1920x1080, 15.6
Power Consumption
-23%
-83%
-32%
-97%
3%
Idle Minimum *
3.85
5.8
-51%
8.9
-131%
3.4
12%
12.6
-227%
4.3
-12%
Idle Average *
7.5
10.4
-39%
13.6
-81%
13.9
-85%
17.1
-128%
7.9
-5%
Idle Maximum *
11.8
13.5
-14%
14.1
-19%
17.6
-49%
19.3
-64%
11.5
3%
Load Average *
47.7
62.4
-31%
100.3
-110%
71.1
-49%
88.3
-85%
43.3
9%
Load Maximum *
90.2
73.1
19%
126.3
-40%
88.5
2%
104
-15%
72.3
20%
Witcher 3 ultra *
46.7
100.2
-115%
57.9
-24%
74.8
-60%

* ... Meglio usare valori piccoli

Autonomia della batteria
Idle (senza WLAN, min luminosità)
16ore 06minuti
Navigazione WiFi v1.3 (Edge)
7ore 37minuti
Big Buck Bunny H.264 1080p
8ore 06minuti
Sotto carico (max luminosità)
1ore 05minuti
HP ZBook 15u G4
7500U, FirePro W4190M, 51 Wh
Lenovo ThinkPad P51s 20HB000SGE
7600U, Quadro M520, 104 Wh
Dell Precision 5520 UHD
E3-1505M v6, Quadro M1200, 97 Wh
Apple MacBook Pro 15 2017 (2.8 GHz, 555)
7700HQ, Radeon Pro 555, 76 Wh
HP ZBook Studio G4-Y6K17EA
E3-1505M v6, Quadro M1200, 64 Wh
HP ZBook 15u G3
6600U, FirePro W4190M, 90 Wh
Autonomia della batteria
140%
-25%
13%
21%
Reader / Idle
966
1581
64%
724
-25%
756
-22%
H.264
486
700
44%
511
5%
WiFi v1.3
457
712
56%
254
-44%
644
41%
312
-32%
Load
65
323
397%
61
-6%
60
-8%
141
117%
Witcher 3 ultra
87
WiFi
162

Pro

+ case in metallo
+ dispositivi di input comodi
+ poco rumorosa
+ display IPS con luminosità superiore a 300 nits
+ molte porte, comprese VGA e DisplayPort full-sized

Contro

- GPU AMD obsoleta
- CPU non abbastanza potente per una workstation portatile
- copertura del colore troppo bassa per l'editing di immagini
- manca una Thunderbolt 3
- temperature elevate sotto carico
- alimentatore da 65 W troppo debole
Recensione: ZBook 15u G4. Modello fornito da HP.
Recensione: ZBook 15u G4. Modello fornito da HP.

CPUs U-class ULV e workstations mobile – due cose che non vanno molto bene insieme. La situazione potrebbe cambiare con i prossimi processori Kaby Lake-R ULV quad-core nel 2018. Tuttavia, per il momento non sono disponibili e non stiamo recensendo un ipotetico ZBook 15u G5 ma lo ZBook 15u G4 con Kaby Lake dual-core.

Il G4 copre il necessario. Case in metallo rigido e di alta qualità con dispositivi di input che, sebbene non della stessa classe, sono adatti ad un dispositivo come questo. Le porte includono VGA ed una DisplayPort full-size, e diversamente dal modello di display business HP EliteBook 850 G4 quello dello ZBook 15u G4 nel complesso è decente: IPS invece di TN, ampi angoli di visuale e una luminosità massima superiore a 300 nits.

L'unica pecca è la copertura del colore sotto la media che potrebbe andare bene per un dispositivo business ma non rispecchia gli elevati standards di una workstation. In aggiunta, avremmo voluto una porta Thunderbolt 3 sul dispositivo - di fatto, ce l'aspettiamo su un dispositivo di questo prezzo. La nostra principale critica riguarda le due unità di processo, CPU e GPU. Entrambe sono veloci quanto ci aspettavamo e sono silenziose (coil-whining a parte). Tuttavia, non sono abbastanza potenti per una moderna workstation. Questo si nota in particolare con l'obsoleta GPU AMD FirePro che dovrebbe essere oramai ritirata dal mercato. Invece, una GPU entry-level Quadro come l'M520 o l'M620 sarebbe stata una scelta migliore. Infine, qualche critica alle temperature di superficie elevate del G$ e all'alimentatore non adeguato.

Sensazioni miste: lo ZBook 15u G4 ha un elevato potenziale, rovinato dalla GPU obsoleta e lenta.

La domanda è: a quali utenti punta HP con lo ZBook 15u G4? Gli utenti workstation che vogliono prestazioni troveranno alternative migliori, come il Dell Precision 5520, l'Apple MacBook Pro 15, o anche l'HP ZBook Studio G4 (attualmente in recensione). Poiché hanno batterie più grandi queste alternative offrono anche una maggiore autonomia. Il G$ inoltre non è la scelta migliore se state cercando una workstation economica ma energeticamente efficiente per applicazioni non pesanti - il Lenovo ThinkPad P51s non ha il case in metallo del G4 ma ha una buona batteria opzionale a 6 celle che incrementa di molto l'autonomia. In aggiunta, ha una Thunderbolt 3 e una GPU più veloce Quadro M520.

Considerando il tutto, possiamo solo concludere che lo ZBook 15u G4 è un portatile decente, ma non regge il confronto con altre workstations mobile. Forse il modello dell'anno prossimo costruito sullo stesso chassis monterà CPUs e GPUs più potenti e le cose cambieranno.

Nota: si tratta di una recensione breve, con alcune sezioni non tradotte, per la versione integrale in inglese guardate qui.





HP ZBook 15u G4 - 09/21/2017 v6
Benjamin Herzig

Chassis
89 / 98 → 91%
Tastiera
85%
Dispositivo di puntamento
88%
Connettività
60 / 81 → 73%
Peso
64 / 66 → 97%
Batteria
90%
Display
86%
Prestazioni di gioco
64%
Prestazioni Applicazioni
93%
Temperatura
84 / 95 → 89%
Rumorosità
93 / 90 → 100%
Audio
55%
Fotocamera
44 / 85 → 52%
Media
75%
81%
Workstation - Media ponderata

Pricecompare

Please share our article, every link counts!
> Recensioni e prove de portatili e telefoni cellulari > Recensioni e prove > Recensioni e prove > Recensione breve della Workstation HP ZBook 15u G4 (7500U, FirePro W4190M)
Benjamin Herzig, 2017-10- 6 (Update: 2017-10- 6)
