Recensione dell'Intel NUC8i3CYSM

Troppo presto per festeggiare? C'è una CPU da 10 nm sul mercato dalla fine del 2018. Intel ha messo un chip basato su Cannon Lake-nel NUC8i3CYSM di Intel, ma ha colto nel segno? L'unità grafica integrata è disattivata per il momento e il chip da 10 nm non offre alcun reale miglioramento delle prestazioni rispetto ai modelli da 14 nm. Inoltre, ha velocità di clock più basse e quindi offre prestazioni peggiori rispetto a simili chip da 14 nm.

No, or more than one (0) Rating for the given SpecsID 309262 found

Intel NUC8i3CYSM
Processore
Intel Core i3-8121U 2 x 2.2 - 3.1 GHz, Cannon-Lake
Scheda grafica
AMD Radeon RX 540 - 2048 MB VRAM, Core: 1124 MHz, Memoria: 1500 MHz, 25.20.15008.2
Memoria
8 GB
, LPDDR4 2400
Scheda madre
Intel Cannon Lake-U PCH-LP Premium
Harddisk
Seagate ST1000VT001, 1024 GB
, 5400 rpm
Scheda audio
ATI Radeon HDMI @ AMD K12 - High Definition Audio Controller
Porte di connessione
1 USB 3.0 / 3.1, 2 HDMI, 1 Kensington Lock, Connessioni Audio: Presa per cuffie/microfono da 3,5 combinata, Lettore schede: SDXC con supporto UHS-I
Rete
Intel Ethernet Connection I219-V (10/100/1000MBit/s), Intel Wireless-AC 9560 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 5.0
Dimensioni
altezza x larghezza x profondità (in mm): 52 x 117 x 112
Sistema Operativo
Microsoft Windows 10 Home 64 Bit
Altre caratteristiche
36 Mesi Garanzia
Peso
660 gr
Prezzo
454.9 Euro
Nota: il produttore potrebbe usare componenti di fornitori diversi pannelli dei diplay, drive o banchi di memoria con specifiche simili.



Confronto Dimensioni

204 mm 129 mm 68 mm 1.1 kg221 mm 142 mm 39 mm 1.3 kg211.1 mm 116.1 mm 27.9 mm 623 g187.6 mm 138.3 mm 37.3 mm 558 g117 mm 112 mm 52 mm 660 g115 mm 111 mm 51 mm 683 g115 mm 111 mm 51 mm 577 g297 mm 210 mm 1 mm 5.7 g
04080120160200240280320360400440480520560600640680Tooltip
Intel NUC8i3CYSM Intel Core i3-8121U, Intel Core i3-8121U: Ø316 (304.79-319.39)
Intel NUC7CJYH Intel Celeron J4005, Intel Celeron J4005: Ø145.7 (143.42-146.64)
Zotac ZBOX-CI660 Nano Intel Core i7-8550U, Intel Core i7-8550U: Ø571 (537.26-702.3)
Chuwi GBox CWI560 Intel Celeron N4100, Intel Celeron N4100: Ø185.6 (184.81-188.15)
Cinebench R15
CPU Single 64Bit
Media della classe Desktop
  (76 - 319, n=34, ultimi 2 anni)
232 Points +74%
Intel NUC8i7BE
Intel Core i7-8559U
188 Points +41%
Intel Hades Canyon NUC8i7HVK
Intel Core i7-8809G
178 Points +34%
Zotac ZBOX-CI660 Nano
Intel Core i7-8550U
156 Points +17%
Intel Skull Canyon NUC6i7KYK
Intel Core i7-6770HQ
139 Points +5%
Intel NUC8i3CYSM
Intel Core i3-8121U
133 Points
Media Intel Core i3-8121U

133 Points 0%
Intel NUC7CJYH
Intel Celeron J4005
77 Points -42%
Chuwi GBox CWI560
Intel Celeron N4100
68 Points -49%
CPU Multi 64Bit
Media della classe Desktop
  (128 - 6236, n=34, ultimi 2 anni)
2501 Points +687%
Intel Hades Canyon NUC8i7HVK
Intel Core i7-8809G
864 Points +172%
Intel NUC8i7BE
Intel Core i7-8559U
798 (671.37min - 798.44max) Points +151%
Intel Skull Canyon NUC6i7KYK
Intel Core i7-6770HQ
711 Points +124%
Zotac ZBOX-CI660 Nano
Intel Core i7-8550U
702 Points +121%
Media Intel Core i3-8121U

318 Points 0%
Intel NUC8i3CYSM
Intel Core i3-8121U
317.6 (304.79min - 319.39max) Points
Chuwi GBox CWI560
Intel Celeron N4100
188 Points -41%
Intel NUC7CJYH
Intel Celeron J4005
144 Points -55%
Cinebench R15 CPU Single 64Bit
133 Points
Cinebench R15 OpenGL 64Bit
76.4 fps
Cinebench R15 Ref. Match 64Bit
98 %
Cinebench R15 CPU Multi 64Bit
317.6 Points
Aiuto
PCMark 10
Score
Media della classe Desktop
  (2317 - 10153, n=24, ultimi 2 anni)
6137 Points +94%
Intel Hades Canyon NUC8i7HVK
Vega M GH, i7-8809G, Intel Optane 120 GB SSDPEK1W120GA
5301 Points +68%
Intel NUC8i7BE
Iris Plus Graphics 655, i7-8559U
4580 Points +45%
Zotac ZBOX-CI660 Nano
UHD Graphics 620, i5-8550U, OCZ Vertex OCZSSD2-1VTX120G
3837 Points +21%
Intel NUC8i3CYSM
Radeon RX 540, i3-8121U, Seagate ST1000VT001
3161 Points
Media Intel Core i3-8121U, AMD Radeon RX 540

3161 Points 0%
Chuwi GBox CWI560
UHD Graphics 600, Celeron N4100, SanDisk DA4064
1658 Points -48%
Intel NUC7CJYH
UHD Graphics 600, Celeron J4005, SanDisk Ultra II
1136 Points -64%
Essentials
Media della classe Desktop
  (5425 - 12421, n=23, ultimi 2 anni)
9601 Points +72%
Intel Hades Canyon NUC8i7HVK
Vega M GH, i7-8809G, Intel Optane 120 GB SSDPEK1W120GA
9125 Points +64%
Intel NUC8i7BE
Iris Plus Graphics 655, i7-8559U
8994 Points +61%
Zotac ZBOX-CI660 Nano
UHD Graphics 620, i5-8550U, OCZ Vertex OCZSSD2-1VTX120G
8051 Points +44%
Intel NUC8i3CYSM
Radeon RX 540, i3-8121U, Seagate ST1000VT001
5576 Points
Media Intel Core i3-8121U, AMD Radeon RX 540

5576 Points 0%
Chuwi GBox CWI560
UHD Graphics 600, Celeron N4100, SanDisk DA4064
4418 Points -21%
Intel NUC7CJYH
UHD Graphics 600, Celeron J4005, SanDisk Ultra II
4188 Points -25%
Productivity
Media della classe Desktop
  (3454 - 12564, n=23, ultimi 2 anni)
8211 Points +55%
Intel Hades Canyon NUC8i7HVK
Vega M GH, i7-8809G, Intel Optane 120 GB SSDPEK1W120GA
7915 Points +49%
Intel NUC8i7BE
Iris Plus Graphics 655, i7-8559U
7236 Points +36%
Zotac ZBOX-CI660 Nano
UHD Graphics 620, i5-8550U, OCZ Vertex OCZSSD2-1VTX120G
6481 Points +22%
Intel NUC8i3CYSM
Radeon RX 540, i3-8121U, Seagate ST1000VT001
5302 Points
Media Intel Core i3-8121U, AMD Radeon RX 540

5302 Points 0%
Intel NUC7CJYH
UHD Graphics 600, Celeron J4005, SanDisk Ultra II
3289 Points -38%
Chuwi GBox CWI560
UHD Graphics 600, Celeron N4100, SanDisk DA4064
2883 Points -46%
Digital Content Creation
Media della classe Desktop
  (1633 - 20009, n=23, ultimi 2 anni)
8585 Points +196%
Intel Hades Canyon NUC8i7HVK
Vega M GH, i7-8809G, Intel Optane 120 GB SSDPEK1W120GA
5598 Points +93%
Intel NUC8i7BE
Iris Plus Graphics 655, i7-8559U
4007 Points +38%
Zotac ZBOX-CI660 Nano
UHD Graphics 620, i5-8550U, OCZ Vertex OCZSSD2-1VTX120G
2939 Points +1%
Intel NUC8i3CYSM
Radeon RX 540, i3-8121U, Seagate ST1000VT001
2902 Points
Media Intel Core i3-8121U, AMD Radeon RX 540

2902 Points 0%
Intel NUC7CJYH
UHD Graphics 600, Celeron J4005, SanDisk Ultra II
990 Points -66%
Chuwi GBox CWI560
UHD Graphics 600, Celeron N4100, SanDisk DA4064
972 Points -67%
Intel NUC8i3CYSM
Seagate ST1000VT001
Intel Skull Canyon NUC6i7KYK
Samsung SSD 850 EVO m.2 120GB
Intel NUC7CJYH
SanDisk Ultra II
Media della classe Desktop

CrystalDiskMark 3.0
Read Seq
47.09
487.6
935%
426.4
806%
2306 ?(64.3 - 5063, n=10, ultimi 2 anni)
4797%
Write Seq
81.4
442.7
444%
443
444%
2218 ?(109.1 - 5683, n=10, ultimi 2 anni)
2625%
Read 512
19.69
420.1
2034%
309.8
1473%
1504 ?(191.3 - 3184, n=10, ultimi 2 anni)
7538%
Write 512
77.9
379.8
388%
365.5
369%
1561 ?(81.7 - 4354, n=10, ultimi 2 anni)
1904%
Read 4k
0.328
38.67
11690%
29.45
8879%
49.7 ?(14.6 - 85.2, n=10, ultimi 2 anni)
15052%
Write 4k
1.434
87.8
6023%
51.7
3505%
170.9 ?(13.1 - 265, n=10, ultimi 2 anni)
11818%
Read 4k QD32
0.857
375.9
43762%
132.8
15396%
513 ?(25.4 - 831, n=10, ultimi 2 anni)
59760%
Write 4k QD32
1.34
309.5
22997%
109
8034%
403 ?(13.1 - 601, n=10, ultimi 2 anni)
29975%
Seagate ST1000VT001
Sequential Read: 47.09 MB/s
Sequential Write: 81.4 MB/s
512K Read: 19.69 MB/s
512K Write: 77.9 MB/s
4K Read: 0.328 MB/s
4K Write: 1.434 MB/s
4K QD32 Read: 0.857 MB/s
4K QD32 Write: 1.34 MB/s
3DMark 11 - 1280x720 Performance GPU
Media della classe Desktop
  (650 - 104464, n=37, ultimi 2 anni)
43908 Points +885%
Intel Hades Canyon NUC8i7HVK
AMD Radeon RX Vega M GH, Intel Core i7-8809G
14302 Points +221%
Media AMD Radeon RX 540
  (4443 - 4983, n=5)
4699 Points +5%
Intel NUC8i3CYSM
AMD Radeon RX 540, Intel Core i3-8121U
4458 Points
Intel Skull Canyon NUC6i7KYK
Intel Iris Pro Graphics 580, Intel Core i7-6770HQ
3220 Points -28%
Intel NUC8i7BE
Intel Iris Plus Graphics 655, Intel Core i7-8559U
3081 Points -31%
Zotac ZBOX-CI660 Nano
Intel UHD Graphics 620, Intel Core i7-8550U
1769 Points -60%
Intel NUC7CJYH
Intel UHD Graphics 600, Intel Celeron J4005
579 Points -87%
Chuwi GBox CWI560
Intel UHD Graphics 600, Intel Celeron N4100
484 Points -89%
3DMark
1920x1080 Fire Strike Graphics
Media della classe Desktop
  (523 - 70246, n=35, ultimi 2 anni)
27704 Points +755%
Intel Hades Canyon NUC8i7HVK
AMD Radeon RX Vega M GH, Intel Core i7-8809G
10248 Points +216%
Media AMD Radeon RX 540
  (3242 - 3876, n=4)
3623 Points +12%
Intel NUC8i3CYSM
AMD Radeon RX 540, Intel Core i3-8121U
3242 Points
Intel NUC8i7BE
Intel Iris Plus Graphics 655, Intel Core i7-8559U
2260 Points -30%
Intel Skull Canyon NUC6i7KYK
Intel Iris Pro Graphics 580, Intel Core i7-6770HQ
1903 Points -41%
Intel NUC7CJYH
Intel UHD Graphics 600, Intel Celeron J4005
448 Points -86%
1280x720 Cloud Gate Standard Graphics
Media della classe Desktop
  (3762 - 246319, n=31, ultimi 2 anni)
96868 Points +418%
Intel Hades Canyon NUC8i7HVK
AMD Radeon RX Vega M GH, Intel Core i7-8809G
59162 Points +216%
Media AMD Radeon RX 540
  (18704 - 25616, n=4)
23165 Points +24%
Intel NUC8i3CYSM
AMD Radeon RX 540, Intel Core i3-8121U
18704 Points
Intel NUC8i7BE
Intel Iris Plus Graphics 655, Intel Core i7-8559U
16698 Points -11%
Intel Skull Canyon NUC6i7KYK
Intel Iris Pro Graphics 580, Intel Core i7-6770HQ
14594 Points -22%
Intel NUC7CJYH
Intel UHD Graphics 600, Intel Celeron J4005
3513 Points -81%
3DMark 06 Standard Score
18661 punti
3DMark 11 Performance
4465 punti
3DMark Cloud Gate Standard Score
9431 punti
3DMark Fire Strike Score
2748 punti
Aiuto
The Witcher 3
1024x768 The Witcher 3 low
Media della classe Desktop
  (11.3 - 790, n=22, ultimi 2 anni)
413 fps
Media AMD Radeon RX 540
  (48 - 50.8, n=2)
49.4 fps
1366x768 The Witcher 3 medium
Media della classe Desktop
  (7.68 - 704, n=26, ultimi 2 anni)
372 fps
Media AMD Radeon RX 540
  (29.3 - 39, n=3)
35.1 fps
1920x1080 The Witcher 3 high
Media della classe Desktop
  (4.18 - 613, n=30, ultimi 2 anni)
294 fps
Media AMD Radeon RX 540
  (8 - 13.2, n=2)
10.6 fps
1920x1080 The Witcher 3 ultra
Media della classe Desktop
  (3.9 - 314, n=30, ultimi 2 anni)
157.9 fps
Media AMD Radeon RX 540
  (6 - 7.8, n=2)
6.9 fps
basso medio alto ultra
Far Cry New Dawn (2019) 40 18 17 16
Anthem (2019) 24 20 17
The Division 2 (2019) 56 39 37 8
Anno 1800 (2019) 54 18 11

Pro

+ design compatto
+ può eseguire i giochi correnti su impostazioni basse
+ ha uno slot M.2
+ scheda microSD
+ nessun throttling

Contro

- Il processo di produzione a 10 nm non apporta miglioramenti di rilievo
- accelera solo fino a 3,2 GHz
- nessun modello con SSD integrato
- iGPU è disabilitata
- manca la porta Thunderbolt
- La RAM è saldata

Sembrerebbe che Intel abbia messo nel NUC8i3CYSM una CPU non completamente pronta. I vantaggi del nuovo processo di produzione a 10 nm non si vedono né sulla carta né nella realtà.

    Il processore Intel Core i3-8121U ha un clock rate inferiore e offre prestazioni peggiori rispetto al processore Intel Core i3-8130U basato su Kaby Lake da 14 nm. Inoltre, entrambe le CPU hanno lo stesso TDP di 15 watt. Attualmente, la iGPU del Core i3-8121U è disabilitata e Intel si affida alla soluzione grafica Radeon di AMD per il rendering delle immagini.

Naturalmente, ci sono anche alcune cose positive da dire sulla nuova CPU, come il fatto che supporta la RAM 2400 MHz LPDDR4, mentre i modelli precedenti non supportavano niente di meglio della RAM 2133 MHz LPDDR3. Il processore Cannon Lake-based offre 16 corsie PCIe 3.0 invece di 12. Tuttavia, Intel non utilizza questo vantaggio, perché ha scelto di inserire un disco rigido nel NUC8i3CYSM. Coloro che vogliono che il sistema sia reattivo dovrebbero prendere in seria considerazione la possibilità di installare un'unità SSD da 2,5 pollici o un'unità SSD M.2. Dato che la RAM è saldata, non è possibile eseguire l'upgrade fino a 16 GB e non ci sono altre opzioni di aggiornamento.

Non si può fare a meno di avere la sensazione che Intel abbia inserito nel NUC una CPU basata su Cannon Lake rilasciata prematuramente. Fortunatamente, è aiutato in modo importante dalla Radeon RX 540 di AMD. Tutto questo significa che non dovreste affrettarvi ad acquistare questo particolare modello solo perché viene prodotto utilizzando il processo di produzione a 10 nm.

No, or more than one (0) Rating for the given SpecsID 309262 found

Pricecompare

Please share our article, every link counts!
Daniel Puschina, 2019-05-22 (Update: 2019-05-22)
