Recensione breve del Convertibile Acer Switch V 10 SW5 (x5-Z8350)

Sascha Mölck (traduzione a cura di G. De Luca), 04/02/2017

Duraturo. Questo convertibile Windows da 10.1 pollici ha un prezzo di circa 360 euro (~ $ 390). Il piccolo dispositivo funziona silenziosamente e offre una lunga durata della batteria. È anche dotato di una porta USB di tipo C (USB 3.1 Gn 1).

Acer Switch V 10 SW5-017-196Q (Aspire Switch Serie)
Processore
Scheda grafica
Intel HD Graphics (Cherry Trail), Core: 200-500 MHz, Single-channel, 20.19.15.4364
Memoria
4096 MB
, DDR3-1600, Single-channel, saldata
Schermo
10.1 pollici 16:10, 1280x800 pixel 149 PPI, Capacitive, 10 touch points, supporto Active stylus, ChiMei, IPS, lucido: si, schermo sganciabile
Harddisk
64 GB eMMC Flash, 64 GB
, 43 GB libera
Porte di connessione
1 USB 2.0, 1 USB 3.0 / 3.1, Connessioni Audio: Audio combo, Lettore schede: MicroSD, 1 Lettore impronte digitali, Sensore luminosità, Sensori: sensore accelerazione, TPM 2.0
Rete
Atheros/Qualcomm QCA6174 (a/b/g/n/ac), Bluetooth 4.1
Dimensioni
altezza x larghezza x profondità (in mm): 19.2 x 262 x 188
Batteria
28.2 Wh ioni di litio, Autonomia della batteria (dichiarata dal produttore): 10 ore
Sistema Operativo
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD
Fotocamera Principale: 5 MPix Webcam
Fotocamera Secondaria: 2 MPix No flash
Altre caratteristiche
Casse: Stereo, Tastiera: Chiclet, Illuminazione Tastiera: no, McAfee LiveSafe (trial version), 12 Mesi Garanzia, senza ventola
Peso
1.2 kg, Alimentazione: 94 gr
Prezzo
359 Euro



Size Comparison

Connectivity

Right side: Power button, Volume rocker, Windows key, USB 2.0 (Type-A)
Right side: Power button, Volume rocker, Windows key, USB 2.0 (Type-A)
Left side: Power connection, USB 3.1 Gen 1 (Type-C), Audio combo, Memory card reader (MicroSD)
Left side: Power connection, USB 3.1 Gen 1 (Type-C), Audio combo, Memory card reader (MicroSD)
Networking
iperf3 Client (receive) TCP 1 m 4M x10
Acer Switch V 10 SW5-017-196Q
Atheros/Qualcomm QCA6174 (RTL GBE)
247 MBit/s ∼100%
iperf3 Client (transmit) TCP 1 m 4M x10
Acer Switch V 10 SW5-017-196Q
Atheros/Qualcomm QCA6174 (RTL GBE)
374 MBit/s ∼100%
iperf Server (receive) TCP 1 m
HP x2 210 G1
Intel Dual Band Wireless-AC 3165
80 MBit/s ∼100%
Lenovo IdeaPad MIIX 310-10ICR
Realtek RTL8723BS
34.95 MBit/s ∼44%
iperf Client (transmit) TCP 1 m
HP x2 210 G1
Intel Dual Band Wireless-AC 3165
71 MBit/s ∼100%
Lenovo IdeaPad MIIX 310-10ICR
Realtek RTL8723BS
37.44 MBit/s ∼53%
238
cd/m²
241
cd/m²
229
cd/m²
232
cd/m²
270
cd/m²
227
cd/m²
242
cd/m²
247
cd/m²
221
cd/m²
Distribuzione della luminosità
X-Rite i1Pro 2
Massima: 270 cd/m² Media: 238.6 cd/m² Minimum: 19 cd/m²
Distribuzione della luminosità: 82 %
Al centro con la batteria: 270 cd/m²
Contrasto: 1286:1 (Nero: 0.21 cd/m²)
ΔE Color 3.01 | - Ø
ΔE Greyscale 7.66 | - Ø
76% sRGB (Argyll) 49% AdobeRGB 1998 (Argyll)
Gamma: 1.45
Acer Switch V 10 SW5-017-196Q
IPS, 1280x800, 10.1
Acer Aspire Switch 10V SW5-014-1742
IPS, 1920x1200, 10.1
Lenovo IdeaPad MIIX 310-10ICR
IPS, 1280x800, 10.1
HP x2 210 G1
IPS, 1280x800, 10.1
Response Times
-10%
-33%
-47%
Response Time Grey 50% / Grey 80% *
29
37
-28%
31.6
-9%
43
-48%
Response Time Black / White *
25
23
8%
24.8
1%
25
-0%
PWM Frequency
877
69.4
-92%
50
-94%
Screen
-3%
-30%
-13%
Brightness
239
440
84%
233
-3%
295
23%
Brightness Distribution
82
85
4%
83
1%
84
2%
Black Level *
0.21
0.48
-129%
0.348
-66%
0.21
-0%
Contrast
1286
940
-27%
724
-44%
1490
16%
Colorchecker DeltaE2000 *
3.01
3.03
-1%
6.35
-111%
6.79
-126%
Greyscale DeltaE2000 *
7.66
1.74
77%
7.09
7%
6.78
11%
Gamma
1.45 166%
2.37 101%
2.02 119%
2.26 106%
CCT
6665 98%
6568 99%
8590 76%
6708 97%
Color Space (Percent of AdobeRGB 1998)
49
43
-12%
52.69
8%
41
-16%
Color Space (Percent of sRGB)
76
59
-22%
63
-17%
Media totale (Programma / Settaggio)
-7% / -5%
-32% / -31%
-30% / -23%

* ... Meglio usare valori piccoli

Screen Flickering / PWM (Pulse-Width Modulation)

To dim the screen, some notebooks will simply cycle the backlight on and off in rapid succession - a method called Pulse Width Modulation (PWM) . This cycling frequency should ideally be undetectable to the human eye. If said frequency is too low, users with sensitive eyes may experience strain or headaches or even notice the flickering altogether.
Screen flickering / PWM detected 877 Hz90 % brightness setting

The display backlight flickers at 877 Hz (Likely utilizing PWM) Flickering detected at a brightness setting of 90 % and below. There should be no flickering or PWM above this brightness setting.

The frequency of 877 Hz is quite high, so most users sensitive to PWM should not notice any flickering.

In comparison: 60 % of all tested devices do not use PWM to dim the display. If PWM was detected, an average of 1486 (minimum: 43 - maximum: 30860) Hz was measured.

Tempi di risposta del Display

I tempi di risposta del display mostrano quanto sia veloce lo schermo a cambaire da un colore all'altro. Tempi di risposta lenti poccono creare sovrapposizioni negloi oggetti in movimento. Specialmente i giocatori patiti del 3D dovrebbero usare uno schermo con rempi di risposta bassi.
       Tempi di risposta dal Nero al Bianco
25 ms ... rise ↗ and fall ↘ combined↗ 9 ms Incremento
↘ 16 ms Calo
Lo schermo mostra tempi di risposta relativamente lenti nei nostri tests e potrebbe essere troppo lento per i gamers.
In comparison, all tested devices range from 0.8 (minimum) to 240 (maximum) ms. » 34 % of all devices are better.
This means that the measured response time is similar to the average of all tested devices (27.2 ms).
       Tempo di risposta dal 50% Grigio all'80% Grigio
29 ms ... rise ↗ and fall ↘ combined↗ 8 ms Incremento
↘ 21 ms Calo
Lo schermo mostra tempi di risposta relativamente lenti nei nostri tests e potrebbe essere troppo lento per i gamers.
In comparison, all tested devices range from 0.9 (minimum) to 636 (maximum) ms. » 11 % of all devices are better.
This means that the measured response time is better than the average of all tested devices (44.1 ms).
Cinebench R10 Rendering Single 32Bit
999
Cinebench R10 Rendering Multiple CPUs 32Bit
3130
Cinebench R10 Shading 32Bit
1984
Cinebench R15 CPU Single 64Bit
29 Points
Cinebench R15 CPU Multi 64Bit
100 Points
Cinebench R15 OpenGL 64Bit
11.16 fps
Cinebench R15 Ref. Match 64Bit
98 %
Aiuto
Cinebench R15
CPU Single 64Bit
Lenovo IdeaPad MIIX 310-10ICR
Intel Atom x5-Z8350
29 Points ∼13% 0%
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
29 Points ∼13%
Acer Aspire Switch 10V SW5-014-1742
Intel Atom x5-Z8300
27 Points ∼12% -7%
HP x2 210 G1
Intel Atom x5-Z8300
26 Points ∼12% -10%
CPU Multi 64Bit
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
100 Points ∼5%
Acer Aspire Switch 10V SW5-014-1742
Intel Atom x5-Z8300
96 Points ∼5% -4%
Lenovo IdeaPad MIIX 310-10ICR
Intel Atom x5-Z8350
94 Points ∼5% -6%
HP x2 210 G1
Intel Atom x5-Z8300
93 Points ∼5% -7%
Cinebench R10
Rendering Single 32Bit
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
999 Points ∼13%
Lenovo IdeaPad MIIX 310-10ICR
Intel Atom x5-Z8350
884 Points ∼12% -12%
HP x2 210 G1
Intel Atom x5-Z8300
855 Points ∼11% -14%
Rendering Multiple CPUs 32Bit
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
3130 Points ∼8%
Lenovo IdeaPad MIIX 310-10ICR
Intel Atom x5-Z8350
2575 Points ∼6% -18%
HP x2 210 G1
Intel Atom x5-Z8300
2135 Points ∼5% -32%
Geekbench 3
32 Bit Multi-Core Score
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
2332 Points ∼7%
32 Bit Single-Core Score
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
796 Points ∼17%
Geekbench 4.0
64 Bit Multi-Core Score
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
2399 Points ∼9%
64 Bit Single-Core Score
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350
934 Points ∼17%
JetStream 1.1 - 1.1 Total Score
Acer Switch V 10 SW5-017-196Q
Intel Atom x5-Z8350 (Edge 38)
45.774 Points ∼0%
HP x2 210 G1
Intel Atom x5-Z8300 (Edge 25.10586.0.0)
44.024 Points ∼0% -4%
Acer Aspire Switch 10V SW5-014-1742
Intel Atom x5-Z8300 (Firefox 43.0.1)
33.52 Points ∼0% -27%
PCMark 8 Home Score Accelerated v2
1520 punti
Aiuto
PCMark 8 - Home Score Accelerated v2
Acer Switch V 10 SW5-017-196Q
HD Graphics (Cherry Trail), Z8350, 64 GB eMMC Flash
1520 Points ∼25%
Lenovo IdeaPad MIIX 310-10ICR
HD Graphics (Cherry Trail), Z8350, 64 GB eMMC Flash
1419 Points ∼24% -7%
HP x2 210 G1
HD Graphics (Cherry Trail), Z8300, 64 GB eMMC Flash
1391 Points ∼23% -8%
64 GB eMMC Flash
Sequential Read: 153.9 MB/s
Sequential Write: 101.1 MB/s
512K Read: 136.2 MB/s
512K Write: 91.51 MB/s
4K Read: 12.58 MB/s
4K Write: 12.38 MB/s
4K QD32 Read: 23.81 MB/s
4K QD32 Write: 33.93 MB/s
Acer Switch V 10 SW5-017-196Q
64 GB eMMC Flash
Acer Aspire Switch 10V SW5-014-1742
Seagate Momentus Thin ST500LT012-1DG142
Lenovo IdeaPad MIIX 310-10ICR
64 GB eMMC Flash
HP x2 210 G1
64 GB eMMC Flash
CrystalDiskMark 3.0
-2%
-14%
-14%
Write 4k QD32
33.93
17.38
-49%
13.18
-61%
11.84
-65%
Read 4k QD32
23.81
33.39
40%
29
22%
35.31
48%
Write 4k
12.38
13.85
12%
12.26
-1%
10.06
-19%
Read 4k
12.58
17.26
37%
9.35
-26%
15.79
26%
Write 512
91.51
26.35
-71%
58.05
-37%
57.69
-37%
Read 512
136.2
149.9
10%
144.5
6%
112.9
-17%
Write Seq
101.1
94.91
-6%
87.29
-14%
66.09
-35%
Read Seq
153.9
167
9%
151.9
-1%
134.1
-13%
3DMark 11 Performance
410 punti
Aiuto
3DMark 11 - 1280x720 Performance GPU
Acer Switch V 10 SW5-017-196Q
Intel HD Graphics (Cherry Trail), Intel Atom x5-Z8350
358 Points ∼1%
Lenovo IdeaPad MIIX 310-10ICR
Intel HD Graphics (Cherry Trail), Intel Atom x5-Z8350
298 Points ∼1% -17%
Acer Aspire Switch 10V SW5-014-1742
Intel HD Graphics (Cherry Trail), Intel Atom x5-Z8300
297 Points ∼1% -17%
HP x2 210 G1
Intel HD Graphics (Cherry Trail), Intel Atom x5-Z8300
291 Points ∼1% -19%
basso medio alto ultra
Trackmania Nations Forever (2008) 97.825fps
Carico massimo
 38 °C29.5 °C26.6 °C
 36.6 °C29.4 °C30.4 °C
 33.5 °C29.2 °C27.4 °C
Massima: 38 °C
Media: 31.2 °C
26.5 °C30.5 °C37.7 °C
26.7 °C31.2 °C37.4 °C
26.6 °C30.6 °C33.6 °C
Massima: 37.7 °C
Media: 31.2 °C
Alimentazione (max)  35.4 °C | Temperatura della stanza 21.3 °C | FIRT 550-Pocket
dB(A) 0102030405060708090Deep BassMiddle BassHigh BassLower RangeMidsHigher MidsLower HighsMid HighsUpper HighsSuper Highs2032.831.632.82537.830.737.83133.831.833.84029.830.729.85033.629.633.66328.627.528.6802726.52710026.425.926.412529.724.829.71603123.73120030.922.830.92502722.32731536.221.136.240051.620.451.650053.219.753.263059.41959.480058.818.858.8100063.418.463.4125062.117.562.1160061.617.661.6200063.517.563.5250065.717.765.7315065.117.965.1400065.21865.250006718.367630067.618.267.6800062.718.362.71000052.218.352.2125004418.2441600041.218.241.2SPL75.930.575.9N34.81.434.8median 58.8Acer Switch V 10 SW5-017-196Qmedian 18.3median 58.8Delta11.51.911.535.335.132.931.831.83236.535.132.428.93328.936.328.848.32761.52752.924.860.92462.822.763.32269.521.267.82174.82075.919.472.718.97117.770.117.86917.671.817.668.117.671.417.673.717.670.417.571.617.671.617.669.617.459.717.583.630.662.51.5median 69.6Apple MacBook 12 (Early 2016) 1.1 GHzmedian 17.84.62.4hearing rangehide median Pink Noise
Acer Switch V 10 SW5-017-196Q audio analysis

(-) | not very loud speakers (66 dB)
Bass 100 - 315 Hz
(-) | nearly no bass - on average 28.6% lower than median
(±) | linearity of bass is average (7.6% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 3.6% away from median
(±) | linearity of mids is average (9.9% delta to prev. frequency)
Highs 2 - 16 kHz
(±) | higher highs - on average 6.7% higher than median
(±) | linearity of highs is average (7.3% delta to prev. frequency)
Overall 100 - 16.000 Hz
(-) | overall sound is not linear (30.1% difference to median)
Compared to same class
» 83% of all tested devices in this class were better, 4% similar, 13% worse
» The best had a delta of 11%, average was 22%, worst was 44%
Compared to all devices tested
» 85% of all tested devices were better, 6% similar, 10% worse
» The best had a delta of 3%, average was 22%, worst was 48%

Apple MacBook 12 (Early 2016) 1.1 GHz audio analysis

(+) | speakers can play relatively loud (83.6 dB)
Bass 100 - 315 Hz
(±) | reduced bass - on average 11.3% lower than median
(±) | linearity of bass is average (14.2% delta to prev. frequency)
Mids 400 - 2000 Hz
(+) | balanced mids - only 2.4% away from median
(+) | mids are linear (5.5% delta to prev. frequency)
Highs 2 - 16 kHz
(+) | balanced highs - only 2% away from median
(+) | highs are linear (4.5% delta to prev. frequency)
Overall 100 - 16.000 Hz
(+) | overall sound is linear (9.3% difference to median)
Compared to same class
» 2% of all tested devices in this class were better, 2% similar, 96% worse
» The best had a delta of 9%, average was 18%, worst was 41%
Compared to all devices tested
» 1% of all tested devices were better, 1% similar, 98% worse
» The best had a delta of 3%, average was 22%, worst was 48%

Consumo di corrente
Off / Standbydarklight 0.25 / 1.24 Watt
Idledarkmidlight 2.9 / 5.3 / 5.6 Watt
Sotto carico midlight 10.9 / 12 Watt
 color bar
Leggenda: min: dark, med: mid, max: light        Metrahit Energy
Autonomia della batteria
Navigazione WiFi v1.3 (Edge 38)
8ore 13minuti
Battery Runtime - WiFi Websurfing 1.3
Lenovo IdeaPad MIIX 310-10ICR
Z8350, HD Graphics (Cherry Trail), 33 Wh
643 min ∼54% +30%
HP x2 210 G1
Z8300, HD Graphics (Cherry Trail), 33 Wh (Edge 25.10586.0.0)
550 min ∼46% +12%
Acer Switch V 10 SW5-017-196Q
Z8350, HD Graphics (Cherry Trail), 28.2 Wh (Edge 38)
493 min ∼41%
Acer Aspire Switch 10V SW5-014-1742
Z8300, HD Graphics (Cherry Trail), 29 Wh
382 min ∼32% -23%

Pro

+ Display IPS
+ silenzioso
+ USB Type-C (USB 3.1 Gen 1)
+ buona autonomia
+ AC WLAN

Contro

- poche connessioni
- keyboard dock instabile
- solo un anno di garanzia
In review: Acer Switch V 10 SW5-017-196Q. Test model courtesy of Acer Germany.
In review: Acer Switch V 10 SW5-017-196Q. Test model courtesy of Acer Germany.

Lo Switch V 10 SW5 è un nuovo laptop convertibile da 10.1 pollici Windows di Acer. Il suo processore Atom ha il giusto livello di potenza per semplici applicazioni da ufficio ed internet. Un decoder integrato nella GPU facilita il lavoro della CPU durante la riproduzione di video in tutti i formati video più comuni. Il dispositivo funziona silenziosamente e difficilmente si riscalda. Dei 64 GB di spazio complessivo, circa 43 GB restano a disposizione dell'utente. Coloro che hanno bisogno di più spazio dovranno fare uso di una scheda microSD. La tastiera è abbastanza buona per uso domestico, anche se non è stato progettato per le persone con mani grandi. Il display IPS delizia l'occhio con i suoi angoli di visione stabili e alto contrasto - anche se potrebbe essere più luminoso.

L'Acer Switch V 10 è un convertibile Windows tuttofare.

Tuttavia, Acer merita qualche critica per la sua avarizia nel campo della connettività. Una seconda porta USB Type-C sul tablet e un altro tipo A-porta USB 3.0 sulla tastiera dock avrebbero completato il computer. Per di più, Acer sta solo offrendo una garanzia di un anno. Siamo abituati a una migliore cura del cliente da questa azienda. Anche i laptops Acer di prezzo più basso in genere sono dotati di una garanzia di due anni.

Nota: si tratta di una recensione breve, con alcune sezioni non tradotte, per la versione integrale in inglese guardate qui.

Acer Switch V 10 SW5-017-196Q - 01/10/2017 v6
Sascha Mölck

Chassis
73 / 98 → 74%
Tastiera
68%
Dispositivo di puntamento
86%
Connettività
38 / 80 → 47%
Peso
73 / 78 → 87%
Batteria
91%
Display
82%
Prestazioni di gioco
37 / 68 → 55%
Prestazioni Applicazioni
42 / 87 → 49%
Temperatura
93%
Rumorosità
100%
Audio
38 / 91 → 41%
Fotocamera
42 / 85 → 49%
Media
66%
79%
Convertible - Media ponderata

Pricecompare

Please share our article, every link counts!
> Recensioni e prove de portatili e telefoni cellulari > Recensioni e prove > Recensioni e prove > Recensione breve del Convertibile Acer Switch V 10 SW5 (x5-Z8350)
Sascha Mölck, 2017-04- 2 (Update: 2017-04- 2)
