Recensione Breve del Convertibile Toshiba Portege Z20t-B

Costoso ma con una autonomia sorprendente. Toshiba richiede 2000 Euro (~$2138) per la configurazione top del suo ultimo convertibile business – in cambio avrete un dispositivo business con molte features ed una autonomia impressionante. Grazie al touchscreen antiriflesso, il Portege Z20t può essere usato anche all'esterno.
PT15BE-00E00FGR (Portege Z20 Serie)
Processore
Intel Core M-5Y71 2 x 1.2 - 2.9 GHz, Broadwell
Scheda grafica
Intel HD Graphics 5300, Core: 900 MHz, Memoria: 800 MHz, Memoria Dual-Channel, 10.18.10.3977
Memoria
8 GB
, Dual-Channel LPDDR3-1600, onboard, non espandibile
Schermo
12.50 pollici 16:9, 1920 x 1080 pixel, capacitive (10 dita) + digitizer, supporto penna nativo, Toshiba TOS508F, Pannello IPS, Retroilluminazione LED, lucido: no, schermo sganciabile
Scheda madre
Intel Broadwell-Y PCH-LP (Premium)
Harddisk
Toshiba HG6 THNSNJ256GVNU, 256 GB
, 198 GB libera
Scheda audio
Intel Broadwell PCH-LP - High Definition Audio Controller
Porte di connessione
1 USB 2.0, 2 USB 3.0 / 3.1, 1 VGA, 1 HDMI, 1 Kensington Lock, 1 Porta Docking, Connessioni Audio: Porta cuffie (3.5 mm stereo jack), Lettore schede: MicroSD, Sensore luminosità, Sensori: Sensore accelerazione 3D, sensore luminosità Ambientale, Giroscopio, VGA, RJ45 Ethernet
Rete
Intel I218-LM Gigabit (10/100/1000MBit/s), Intel Dual Band Wireless-AC 7265 (a/b/g/h/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.0, Sierra Wireless EM7305 Mobile Broadband 3G/LTE (4G), LTE
Dimensioni
altezza x larghezza x profondità (in mm): 21 x 309 x 215
Batteria
72 Wh polimeri di litio, 36 Wh (tablet) + 36 Wh (dock)
Sistema Operativo
Microsoft Windows 8.1 Pro 64 Bit
Camera
Webcam: 2.0 MP (frontale) + 5.0 MP (posteriore)
Fotocamera Principale: 5 MPix
Fotocamera Secondaria: 2 MPix
Altre caratteristiche
Casse: Stereo, Tastiera: Chiclet, Illuminazione Tastiera: si, 2x Digitizer + 3 spare tips, alimentatore da 45-watt, brochures, Toshiba System Settings, Toshiba Tempro, Eco Utility, 12 Mesi Garanzia, senza ventola
Peso
1.493 kg, Alimentazione: 150 gr
Prezzo
2000 Euro
Nota: il produttore potrebbe usare componenti di fornitori diversi pannelli dei diplay, drive o banchi di memoria con specifiche simili.



Top: No ports
Top: No ports
Left: Kensington Lock, VGA, HDMI
Left: Kensington Lock, VGA, HDMI
Right: SIM slot, On/Off, volume rocker, micro-USB 2.0, micro-HDMI, microSD, headset port (top); 2x USB 3.0, Gbit-LAN, AC power (bottom)
Right: SIM slot, On/Off, volume rocker, micro-USB 2.0, micro-HDMI, microSD, headset port (top); 2x USB 3.0, Gbit-LAN, AC power (bottom)
Bottom: Stylus, docking port, AC power
Bottom: Stylus, docking port, AC power
310
cd/m²
331
cd/m²
301
cd/m²
314
cd/m²
342
cd/m²
292
cd/m²
282
cd/m²
279
cd/m²
260
cd/m²
Distribuzione della luminosità
Toshiba TOS508F tested with X-Rite i1Pro 2
Massima: 342 cd/m² (Nits) Media: 301.2 cd/m²
Distribuzione della luminosità: 76 %
Al centro con la batteria: 341 cd/m²
Contrasto: 870:1 (Nero: 0.393 cd/m²)
ΔE Color 9.69 | 0.5-29.43 Ø5
ΔE Greyscale 9.27 | 0.57-98 Ø5.3
40.4% AdobeRGB 1998 (Argyll 1.6.3 3D)
44.1% AdobeRGB 1998 (Argyll 2.2.0 3D)
63.6% sRGB (Argyll 2.2.0 3D)
42.63% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.95
Toshiba Portege Z20t-B-10C
1.920 x 1.080; IPS-Panel
Lenovo ThinkPad Helix 2
1.920 x 1.080; IPS-Panel
Microsoft Surface Pro 3
2.160 x 1.440; IPS-Panel
Dell Venue 11 Pro 7140
1.920 x 1.080; IPS-Panel
Display
46%
Display P3 Coverage
42.63
63.6
49%
sRGB Coverage
63.6
88.8
40%
AdobeRGB 1998 Coverage
44.1
65.6
49%
Screen
29%
26%
22%
Brightness middle
342
365
7%
355.3
4%
386
13%
Brightness
301
342
14%
338
12%
357
19%
Brightness Distribution
76
86
13%
91
20%
84
11%
Black Level *
0.393
0.329
16%
0.33
16%
0.4
-2%
Contrast
870
1109
27%
1077
24%
965
11%
Colorchecker dE 2000 *
9.69
4.37
55%
4.72
51%
3.71
62%
Greyscale dE 2000 *
9.27
2.8
70%
6.53
30%
5.4
42%
Gamma
2.95 75%
2.3 96%
2.17 101%
2.33 94%
CCT
6010 108%
6595 99%
6707 97%
6666 98%
Color Space (Percent of AdobeRGB 1998)
40.4
59.37
47%
Media totale (Programma / Settaggio)
29% / 29%
36% / 31%
22% / 22%

* ... Meglio usare valori piccoli

Cinebench R11.5
CPU Single 64Bit (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71
1.15 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71
1.13 Points -2%
Microsoft Surface Pro 3
Intel Core i5-4300U
1.12 Points -3%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a
0.94 Points -18%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y
1.24 Points +8%
CPU Multi 64Bit (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71
2.14 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71
2.04 Points -5%
Microsoft Surface Pro 3
Intel Core i5-4300U
2.77 Points +29%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a
2.01 Points -6%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y
2.15 Points 0%
Cinebench R15
CPU Single 64Bit (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71
97 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71
95 Points -2%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a
83 Points -14%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y
107 Points +10%
CPU Multi 64Bit (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71
190 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71
184 Points -3%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a
190 Points 0%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y
192 Points +1%
X264 HD Benchmark 4.0
Pass 1 (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71
85.1 fps
Lenovo ThinkPad Helix 2
Intel Core M-5Y71
91.2 fps +7%
Microsoft Surface Pro 3
Intel Core i5-4300U
75.5 fps -11%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y
72.5 fps -15%
Pass 2 (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71
11.47 fps
Lenovo ThinkPad Helix 2
Intel Core M-5Y71
11.13 fps -3%
Microsoft Surface Pro 3
Intel Core i5-4300U
13.47 fps +17%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y
12.38 fps +8%
Cinebench R10 Shading 32Bit
4680
Cinebench R10 Rendering Multiple CPUs 32Bit
6606
Cinebench R10 Rendering Single 32Bit
3810
Cinebench R10 Shading 64Bit
3681 Points
Cinebench R10 Rendering Multiple CPUs 64Bit
8486 Points
Cinebench R10 Rendering Single CPUs 64Bit
5068 Points
Cinebench R11.5 CPU Single 64Bit
1.15 Points
Cinebench R11.5 OpenGL 64Bit
17.84 fps
Cinebench R11.5 CPU Multi 64Bit
2.14 Points
Cinebench R15 Ref. Match 64Bit
98 %
Cinebench R15 OpenGL 64Bit
20.74 fps
Cinebench R15 CPU Multi 64Bit
190 Points
Cinebench R15 CPU Single 64Bit
97 Points
Aiuto
Toshiba HG6 THNSNJ256GVNU
Valore Minimo di trasferimento: 253.3 MB/s
Valore Massimo di trasferimento: 413.9 MB/s
Valore Medio di trasferimento: 334.2 MB/s
Tempi di accesso: 0.1 ms
Burst Rate: 200.4 MB/s
Utilizzo CPU: 2.5 %
PCMark 7 - Score (ordina per valore)
Toshiba Portege Z20t-B-10C
HD Graphics 5300, 5Y71, Toshiba HG6 THNSNJ256GVNU
4421 Points
Lenovo ThinkPad Helix 2
HD Graphics 5300, 5Y71, Toshiba THNSFJ256GDNU 256 GB
4602 Points +4%
Microsoft Surface Pro 3
HD Graphics 4400, 4300U, Hynix HFS128G3MNM
5066 Points +15%
Dell Venue 11 Pro 7140
HD Graphics 5300, 5Y10a, Sandisk X110 M.2 SD6SP1M-128G
4135 Points -6%
Toshiba Portege Z10t-A2111
HD Graphics 4200, 4610Y, Samsung PM851 Series MZMTE256HMHP
4973 Points +12%
PCMark 8
Home Score Accelerated v2 (ordina per valore)
Toshiba Portege Z20t-B-10C
HD Graphics 5300, 5Y71, Toshiba HG6 THNSNJ256GVNU
2816 Points
Lenovo ThinkPad Helix 2
HD Graphics 5300, 5Y71, Toshiba THNSFJ256GDNU 256 GB
2690 Points -4%
Dell Venue 11 Pro 7140
HD Graphics 5300, 5Y10a, Sandisk X110 M.2 SD6SP1M-128G
2480 Points -12%
Toshiba Portege Z10t-A2111
HD Graphics 4200, 4610Y, Samsung PM851 Series MZMTE256HMHP
2282 Points -19%
Work Score Accelerated v2 (ordina per valore)
Toshiba Portege Z20t-B-10C
HD Graphics 5300, 5Y71, Toshiba HG6 THNSNJ256GVNU
3936 Points
Lenovo ThinkPad Helix 2
HD Graphics 5300, 5Y71, Toshiba THNSFJ256GDNU 256 GB
3806 Points -3%
Dell Venue 11 Pro 7140
HD Graphics 5300, 5Y10a, Sandisk X110 M.2 SD6SP1M-128G
3291 Points -16%
Toshiba Portege Z10t-A2111
HD Graphics 4200, 4610Y, Samsung PM851 Series MZMTE256HMHP
3441 Points -13%
Creative Score Accelerated v2 (ordina per valore)
Toshiba Portege Z20t-B-10C
HD Graphics 5300, 5Y71, Toshiba HG6 THNSNJ256GVNU
3263 Points
Lenovo ThinkPad Helix 2
HD Graphics 5300, 5Y71, Toshiba THNSFJ256GDNU 256 GB
3090 Points -5%
Toshiba Portege Z10t-A2111
HD Graphics 4200, 4610Y, Samsung PM851 Series MZMTE256HMHP
2400 Points -26%
PCMark 7 Score
4421 punti
PCMark 8 Home Score Accelerated v2
2816 punti
PCMark 8 Creative Score Accelerated v2
3263 punti
PCMark 8 Work Score Accelerated v2
3936 punti
Aiuto
3DMark 11 - 1280x720 Performance (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71, Intel HD Graphics 5300
775 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71, Intel HD Graphics 5300
753 Points -3%
Microsoft Surface Pro 3
Intel Core i5-4300U, Intel HD Graphics 4400
877 Points +13%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a, Intel HD Graphics 5300
883 Points +14%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y, Intel HD Graphics 4200
784 Points +1%
Lenovo ThinkPad T450s-20BWS03F00
Intel Core i7-5600U, Intel HD Graphics 5500
1251 Points +61%
3DMark
1280x720 Ice Storm Standard Score (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71, Intel HD Graphics 5300
35835 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71, Intel HD Graphics 5300
35119 Points -2%
Microsoft Surface Pro 3
Intel Core i5-4300U, Intel HD Graphics 4400
29229 Points -18%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a, Intel HD Graphics 5300
38912 Points +9%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y, Intel HD Graphics 4200
32971 Points -8%
Lenovo ThinkPad T450s-20BWS03F00
Intel Core i7-5600U, Intel HD Graphics 5500
55793 Points +56%
1280x720 Cloud Gate Standard Score (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71, Intel HD Graphics 5300
3585 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71, Intel HD Graphics 5300
3522 Points -2%
Microsoft Surface Pro 3
Intel Core i5-4300U, Intel HD Graphics 4400
4146 Points +16%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a, Intel HD Graphics 5300
3484 Points -3%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y, Intel HD Graphics 4200
3754 Points +5%
Lenovo ThinkPad T450s-20BWS03F00
Intel Core i7-5600U, Intel HD Graphics 5500
5782 Points +61%
1920x1080 Fire Strike Score (ordina per valore)
Toshiba Portege Z20t-B-10C
Intel Core M-5Y71, Intel HD Graphics 5300
453 Points
Lenovo ThinkPad Helix 2
Intel Core M-5Y71, Intel HD Graphics 5300
450 Points -1%
Microsoft Surface Pro 3
Intel Core i5-4300U, Intel HD Graphics 4400
483 Points +7%
Dell Venue 11 Pro 7140
Intel Core M-5Y10a, Intel HD Graphics 5300
466 Points +3%
Toshiba Portege Z10t-A2111
Intel Core i7-4610Y, Intel HD Graphics 4200
495 Points +9%
Lenovo ThinkPad T450s-20BWS03F00
Intel Core i7-5600U, Intel HD Graphics 5500
753 Points +66%
3DMark 06 Standard Score
5273 punti
3DMark 11 Performance
775 punti
3DMark Ice Storm Standard Score
35835 punti
3DMark Cloud Gate Standard Score
3585 punti
3DMark Fire Strike Score
453 punti
Aiuto
basso medio alto ultra
Tomb Raider (2013) 40.3 20.5 13.5
Alien: Isolation (2014) 23.9 15.9 8.5
F1 2014 (2014) 39 25 14
 23.3 °C25.7 °C27.4 °C
 23.9 °C26.2 °C28.8 °C
 26 °C28.9 °C28 °C
Massima: 28.9 °C
Media: 26.5 °C
26.9 °C25.7 °C23.9 °C
27.7 °C25.9 °C24.2 °C
26.9 °C26 °C25.3 °C
Massima: 27.7 °C
Media: 25.8 °C
Alimentazione (max)  31.3 °C | Temperatura della stanza 20.1 °C | Fluke 62 Max
(±) La temperatura media del lato superiore sotto carico massimo e' di 35.2 °C / 95 F, rispetto alla media di 30.2 °C / 86 F per i dispositivi di questa classe Convertible.
(-) La temperatura massima sul lato superiore è di 48.3 °C / 119 F, rispetto alla media di 35.3 °C / 96 F, che varia da 19.6 a 55.7 °C per questa classe Convertible.
(±) Il lato inferiore si riscalda fino ad un massimo di 43.2 °C / 110 F, rispetto alla media di 36.7 °C / 98 F
(+) In idle, la temperatura media del lato superiore è di 26.5 °C / 80 F, rispetto alla media deld ispositivo di 30.2 °C / 86 F.
(-) I poggiapolsi e il touchpad possono diventare molto caldi al tatto con un massimo di 43 °C / 109.4 F.
(-) La temperatura media della zona del palmo della mano di dispositivi simili e'stata di 28.1 °C / 82.6 F (-14.9 °C / -26.8 F).
Consumo di corrente
Off / Standbydarklight 0 / 0.1 Watt
Idledarkmidlight 2.4 / 4.6 / 5.6 Watt
Sotto carico midlight 15.6 / 30.7 Watt
 color bar
Leggenda: min: dark, med: mid, max: light        Extech Power Analyzer 380803
Attualmente utilizziamo il Metrahit Energy, un multimetro digitale professionale per la misurazione della qualità della potenza e dell'energia monofase, per le nostre misurazioni.
Toshiba Portege Z20t-B-10C
72 Wh
Lenovo ThinkPad Helix 2
35 Wh
Microsoft Surface Pro 3
42 Wh
Dell Venue 11 Pro 7140
38 Wh
Autonomia della batteria
-46%
-48%
-41%
Reader / Idle
1616
964
-40%
1096
-32%
777
-52%
H.264
787
360
-54%
WiFi v1.3
760
Load
348
197
-43%
124
-64%
244
-30%
WiFi
396
504
562
Autonomia della batteria
Idle (senza WLAN, min luminosità)
26ore 56minuti
WiFi Websurfing
12ore 40minuti
Big Buck Bunny H.264 1080p
13ore 07minuti
Sotto carico (max luminosità)
5ore 48minuti

Pro

+ Qualità elevata
+ Dispositivi di input eccellenti
+ Supporto Digitizer
+ Pannello IPS antiriflesso con immagini buone
+ Ottime prestazioni per il quotidiano
+ Raffreddamento Passivo
+ Impressionante autonomia

Contro

- Solo 12 mesi di garanzia
- Nessuna possibilità di upgrade
- Manca il lettore di impronte digitali
- Prezzo estremamente alto
Toshiba Portege Z20t
Toshiba Portege Z20t

Sorprende sempre vedere quanto siano diventati portatili e potenti i moderni convertibilo – un dispositivo Core-M a raffreddamento passivo è difficilmente più lento di un vero PC desktop in molte situazioni quotidiane: ma oltre a Toshiba, i rivali come Lenovo o Dell ci riescono abbastanza bene ed usano la stessa piattaforma hardware per i loro dispositivi.

Quindi perché dovremmo spendere quasi 2000 Euro (~$2138) per il Portege Z20t, se possamo avere un ThinkPad Helix 2 o un Venue 11 Pro per un prezzo nettamente inferiore? Dobbiamo essere onesti ed enfatizzare il fatto che Toshiba ha molti accessori, che devono essere acquistati separatamente nel caso dei concorrenti. Oltre a due digitizers ed un modulo LTE integrato, parliamo della tastiera dock con una seconda batteria, che consente una autonomia estremamente ampia. Il touchscreen matto del Portege è un'altra caratteristica unica ed estremamente utile all'aperto. La qualità del portatile 2-in-1 non mostra alcun problema: l'assemblaggio è molto buono ed i dispositivi di input sono adatti a chi scrive molto.

Nel complesso, il Portege Z20t è un interessante dispositivo per i facoltosi clienti business che cercano un compagno versatile con una ottima mobilità. I clienti privati possono fare a meno di alcune features e soluzioni di sicurezza e quindi possono cercare qualcosa di più economico.

Nota: si tratta di una recensione breve, con alcune sezioni non tradotte, per la versione integrale in inglese guardate qui.

Toshiba Portege Z20t-B-10C - 04/18/2016 v5.1(old)
Till Schönborn

Chassis
82 / 98 → 83%
Tastiera
84%
Dispositivo di puntamento
93%
Connettività
69 / 80 → 86%
Peso
69 / 35-78 → 79%
Batteria
95%
Display
84%
Prestazioni di gioco
53 / 68 → 78%
Prestazioni Applicazioni
73 / 87 → 84%
Temperatura
88%
Rumorosità
100%
Audio
44 / 91 → 48%
Fotocamera
61 / 85 → 71%
Media
76%
85%
Convertible - Media ponderata

Pricecompare

Please share our article, every link counts!
> Recensioni e prove di notebook, tablets e smartphones > Recensioni e prove > Recensioni e prove > Recensione Breve del Convertibile Toshiba Portege Z20t-B
Till Schönborn, 2015-04-30 (Update: 2015-04-30)
