Communication

The sole connectivity to the outside world consists of a RealTek RTL8821AE 802.11ac 1x1 combo module, which supports both 2.4 GHz and 5 GHz. Bluetooth 4.0 is on board as well. We had no issues with the reception strength and never had any problems or dropped connections during our time with the review model.

Accessories

Lenovo bundles both an AccuType wireless keyboard as well as a wireless mouse. Optional accessories include a joystick, striker, and e-dice, which directly interact with touchscreen or application/games. The joystick/striker combo (2 sets) sells for $50. Unfortunately, our review model did not come with the accessories, so we couldn't check out the functionality they provide.

Maintenance

According to the hardware manual, access to the hardware requires the removal of only two screws. Unfortunately, the back cover resisted our efforts to remove it and we stopped to avoid any damage.

Warranty

Lenovo offers a 12-month warranty against manufacturer's defects. At the time of writing, the online configurator did not allow us to choose longer or different warranty options.

183.9
cd/m²
177.1
cd/m²
183.5
cd/m²
185.5
cd/m²
197.2
cd/m²
182.7
cd/m²
186.2
cd/m²
171.4
cd/m²
176.8
cd/m²
Distribuzione della luminosità
LEN8000 tested with X-Rite i1Pro 2
Massima: 197.2 cd/m² (Nits) Media: 182.7 cd/m²
Distribuzione della luminosità: 87 %
Al centro con la batteria: 197.2 cd/m²
Contrasto: 1120:1 (Nero: 0.176 cd/m²)
ΔE Color 6.31 | 0.5-29.43 Ø5
ΔE Greyscale 8.21 | 0.57-98 Ø5.3
52.97% AdobeRGB 1998 (Argyll 1.6.3 3D)
59.5% AdobeRGB 1998 (Argyll 2.2.0 3D)
80.7% sRGB (Argyll 2.2.0 3D)
61.3% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.18
Cinebench R10 Shading 64Bit
4832 Points
Cinebench R10 Rendering Multiple CPUs 64Bit
7841 Points
Cinebench R10 Rendering Single CPUs 64Bit
3137 Points
Cinebench R11.5 OpenGL 64Bit
10.98 fps
Cinebench R11.5 CPU Multi 64Bit
2.02 Points
Cinebench R11.5 CPU Single 64Bit
0.6 Points
Cinebench R15 Ref. Match 64Bit
98 %
Cinebench R15 OpenGL 64Bit
20.35 fps
Cinebench R15 CPU Multi 64Bit
189 Points
Cinebench R15 CPU Single 64Bit
62 Points
Aiuto
PCMark 7 Score
2426 punti
PCMark 8 Home Score Accelerated v2
2010 punti
PCMark 8 Creative Score Accelerated v2
2143 punti
PCMark 8 Work Score Accelerated v2
2825 punti
Aiuto
3DMark 06 Standard Score
4136 punti
3DMark Vantage P Result
3218 punti
3DMark 11 Performance
785 punti
3DMark Ice Storm Standard Score
30261 punti
3DMark Cloud Gate Standard Score
3578 punti
3DMark Fire Strike Score
479 punti
Aiuto
basso medio alto ultra
Tomb Raider (2013) 36.5

Emissions

System Noise

Although the fan of the Horizon 2e is running at all times, the system is overall very quiet. We measured a maximum of 33.1 dB during idle, which is a bit higher than both the Dell and the Sony. The whooshing of the hard drive is more audible than the fan under normal idle conditions, however. Under load, the system does not get much louder and we measured a maximum of only 34.8 dB. The frequency of the fan is very unobtrusive, so even extended sessions at maximum performance never get annoying. Both the Dell XPS 18 and the Sony Vaio Tap 20 emit around 40 dB under load.

Il Lenovo Horizon 2e è un interessante modello All-In-One. Il sistema può essere usato al meglio a casa, siccome spostarlo di più di qualche metro è scomodo, considerando dimensioni e peso. Non possiamo commentare su come il dispositivo si comporta come strumento per più persone, perché non abbiamo ricevuto gli optional. L'interfaccia Aura è un interessante add-on che permette di accedere ai file multimediali sul sistema o su un dispositivo Android in un modo unico e futuristico. Ci siamo ritrovati a usare la modalità stand molto più frequentemente delle altre, perché non abbiamo potuto trovare molti tipi di utilizzo per un tablet di queste dimensioni.

Le prestazioni sono adeguate per un utente consumer, ma gli appassionati di giochi dovrebbero rivolgersi a un altro prodotto. Nonostante qualche difetto, tastiera e mouse sono discreti e sufficienti per la maggior parte degli utenti. Il display soffre di scarsa luminosità, anche se gli angoli di visualizzazione sono ottimi. Anche se l'autonomia della batteria non è straordinaria, non siamo sicuri che autonomie superiori siano realmente necessarie per un dispositivo di questo tipo. Di fatto, alcuni utenti potrebbero benissimo rivolgersi a un normale AIO senza batteria. La stessa Lenovo ha creato il B40 All-In-One, per esempio, che monta una più potente CPU Intel Core i3-4150T CPU con Intel HD Graphics 4600, un disco fisso da 7200 RPM e 1 TB, lettore DVD integrato a un prezzo inferiore a 700 dollari.

Il Lenovo Horizon 2e...
Il Lenovo Horizon 2e...
...è un sistema 2-in-1 sottole...
...è un sistema 2-in-1 sottole...
...con uno stand regolabile e una batteria inclusa.
...con uno stand regolabile e una batteria inclusa.
L'angolo massimo è di 73 gradi.
L'angolo massimo è di 73 gradi.
Lo stand si ripiega contro il pannello posteriore, ma non affonda in esso
Lo stand si ripiega contro il pannello posteriore, ma non affonda in esso
L'Horizon 2e a fianco del Dell XPS 18
L'Horizon 2e a fianco del Dell XPS 18
Il Dell ha un display più piccolo, è molto più sottile e ha meno porte
Il Dell ha un display più piccolo, è molto più sottile e ha meno porte
Con lo stand optional, il Dell XPS è un po' più alto.
Con lo stand optional, il Dell XPS è un po' più alto.
I depliant inclusi.
I depliant inclusi.
L'alimentatore con il nuovo connettore quadrato è da 90 watt.
L'alimentatore con il nuovo connettore quadrato è da 90 watt.
Tra le cerniere si trova la batteria da 47 Wh
Tra le cerniere si trova la batteria da 47 Wh
Il pannello posteriore può essere staccato rimuovendo due viti.
Il pannello posteriore può essere staccato rimuovendo due viti.
La plastica sul retro favorisce l'aderenza.
La plastica sul retro favorisce l'aderenza.
Abbiamo, però, trovato più sicuro usare lo stand come maniglia.
Abbiamo, però, trovato più sicuro usare lo stand come maniglia.
Il pulsante Windows con il feedback feedback tattile
Il pulsante Windows con il feedback feedback tattile
Please share our article, every link counts!

Specifiche tecniche

Lenovo Horizon 2e-F0AS0014US
Processore
Intel Core i3-4030U 2 x 1.9 GHz, Haswell
Scheda grafica
Intel HD Graphics 4400, Core: 600 MHz, Memoria: 800 MHz
Memoria
4 GB
, PC3-12800 DDR3
Schermo
21.50 pollici 16:9, 1920 x 1080 pixel, 10 punti, LEN8000, IPS, lucido: no
Scheda madre
Intel Lynx Point-LP
Harddisk
WDC WD10JPVX-08JC3T5, 1000 GB
, 5400 rpm
Scheda audio
Intel Lynx Point-LP - High Definition Audio Controller
Porte di connessione
3 USB 3.0 / 3.1, 1 HDMI, Connessioni Audio: jack combinato 3.5 mm, Lettore schede: 6-in-1 , Sensori: Luce ambientale, NFC
Rete
Realtek RTL8821AE 802.11ac (), Bluetooth 4.0
Dimensioni
altezza x larghezza x profondità (in mm): 319 x 525.8 x 39.9
Batteria
47 Wh ioni di litio, Autonomia della batteria (dichiarata dal produttore): 3 ore
Sistema Operativo
Microsoft Windows 8.1 64 Bit
Camera
Webcam: 2.1 MP
Altre caratteristiche
Casse: Altoparlante stereo con Dolby Home Theater, Illuminazione Tastiera: no, Optional: joystick, striker, e-dice, 12 Mesi Garanzia
Peso
4.581 kg, Alimentazione: 422 gr
Prezzo
719 Euro



Portatili con medesima GPU

Recensione breve del Convertibile Asus Q302LA
HD Graphics 4400, Core i3 4030U, 13.30", 1.814 kg
Recensione Breve del Convertibile Acer Aspire R13 R7-371T-779K
HD Graphics 4400, Core i7 4510U, 13.30", 1.46 kg
Recensione breve dell'AIO Lenovo Horizon 2s-F0AT0003US
HD Graphics 4400, Core i5 4210U, 19.50", 2.478 kg
Recensione breve del convertibile Toshiba Satellite Radius P50W-BST2N01
HD Graphics 4400, Core i5 4210U, 15.60", 2.168 kg
Recensione del convertibile Dell Inspiron 13 7347
HD Graphics 4400, Core i5 4210U, 13.30", 1.65 kg
Recensione breve del Convertibile HP Pavilion 13-a000ng x360
HD Graphics 4400, Core i3 4030U, 13.30", 1.76 kg

Pro

+Display non riflettente (IPS) con buona stabilità degli angoli di visualizzazione
+Touchscreen con ottima reattività
+Design compatto
+Stand integrato
+Molto silenzioso
+3 porte USB 3.0
+Buona interfaccia Aura


Contro

-Schermo poco luminoso
-Un po' pesante
-Autonomia della batteria non eccezionale
-La tastiera si piega troppo
-Numero limitato di risoluzioni dello schermo
-Hard drive lento

Lenovo Horizon 2e-F0AS0014US - 11/04/2014 v4(old)
Bernhard Pechlaner

Chassis
74 / 98 → 76%
Tastiera
69%
Dispositivo di puntamento
89%
Connettività
60 / 80 → 75%
Peso
43 / 35-78 → 19%
Batteria
70%
Display
79%
Prestazioni di gioco
61 / 68 → 89%
Prestazioni Applicazioni
66 / 87 → 76%
Temperatura
87%
Rumorosità
88%
Audio
68 / 91 → 75%
Fotocamera
71 / 85 → 84%
Punti aggiuntivi
+3%
Media
66%
71%
Convertible - Media ponderata
